3/4 in. Brass Standard Port PEX Ball Valve
Jomar International
3/4 in. Brass Standard Port PEX Ball Valve
Package Quantity Info:
Each: 1 Inner Pack: 1
How to get it:
-
-
Shipping Not AvailableNot available at this time
Purchase history
Jomar International
3/4 in. Brass Standard Port PEX Ball Valve
103-524PG
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- Dezincification resistant brass
- Gland follower and single O-ring stem design
- Blow-out proof stem
- 100% leak tested
- Wetted surfaces contain less than .25% lead content
Product Information
-
Lead Law Compliant
Documents
Dimensions & Measurements
End Connection 1
Barbed
End Connection 2
Barbed
End Connections
Barbed
Length
2-18/25 in
Valve Size
3/4 in
Characteristics & Features
Clean Bagged
No
Handle Material
Steel
Material
Brass
Valve Body Style
2 piece
Valve Disc Material
Chrome Plated Brass
Valve Operator
Lever Handle
Valve Port Opening
Standard Port
Valve Seat Material
PTFE
Valve Stem
Blowout-Proof
Valve Type
Ball Valve
Electrical & Operational Information
Pressure - High
100, 400
Temperature Range
Up to 180 Deg F
Warranty & Product Information
ANSI
ANSI 14 2014, ANSI Z1157 2014
ASME
ASME A112.4.14
ASTM
ASTM F-1807
FM Approved
No
IAPMO Listed
Yes
Lead Law Compliance Level
Lead Law Compliant and Certified
Lead Law Compliant
Yes
NSF
NSF 14 2014, NSF 372, NSF 61-8
NSF Certified
Yes
Recommended Valve Application
Gas, Oil, Water
UL Listed
No
UPC
662527293640
