1 x 3/4 x 10-1/4 in. Female Carbon Steel Reducing Nipple
1 x 3/4 x 10-1/4 in. Female Carbon Steel Reducing Nipple
Package Quantity Info:
Each: 1
How to get it:
-
-
Shipping Not AvailableNot available at this time
Purchase history
1 x 3/4 x 10-1/4 in. Female Carbon Steel Reducing Nipple
90203E1007
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- Labor saving by eliminating expensive cutting and re-fitting of the drop nipple in flush to ceiling and wall installations
- Designed for wet or dry automatic fire sprinkler systems in accordance to NFPA 13, 13R, & 13D
- Allows direct attachment to branch connection with available male inlet
- UL listed in accordance to UL 1474 5th edition with qualifying tests up to 1500 psi
- FM approved in accordance to FM Class 1631 with qualifying tests up to 1200 psi
- Precision machined to very close tolerances with threads conforming to ANSI B1.20.1 NPT or better
- Increased corrosion resistance
- Fully traceable with a lot number marked on each unit
- All material batches are checked by independent laboratories to insure all material standards are met and each unit is pressure tested prior to shipment
- Made in USA from up to 85% recycled steel
Dimensions & Measurements
End Connection 1
FPT
End Connection 2
FPT
End Connections
FPT
Fitting Size 1
1 in
Fitting Size 2
3/4 in
Fitting Sizes
1 in x 3/4 in
Length
10-1/4 in
Pressure Class
300#
Characteristics & Features
Coating
Zinc Plated
Fitting Type
Nipple, Reducer
Material
Carbon Steel
Material Type
EPDM
Warranty & Product Information
ANSI
ANSI B1.20.1
Application
Fire Protection
FM Approved
Yes
IAPMO Listed
No
ISO
ISO 7-1
NSF Certified
No
Origin
Domestic
UPC
860008905178
