Specifications

ANSI:

ANSI 372, ANSI 61, ANSI A21.10, ANSI B2.1, ANSI C515, ANSI C550

ASME:

ASME B16.1, ASME B16.4

ASTM:

ASTM A-126, ASTM A-536, ASTM D-1785, ASTM D-2000, ASTM D-2241

AWWA:

AWWA C-110, AWWA C-111, AWWA C-515, AWWA C-550

Application:

Fire, Irrigation, Potable Water, Sewage

Coating:

Fusion Bonded Epoxy

Ductile Iron Pipe Type:

Ductile Iron Mechanical Joint Pipe

End Connection 1:

Mechanical Joint

End Connection 2:

Mechanical Joint

End Connections:

Mechanical Joint x Mechanical Joint

FM Approved:

Yes

Length:

25-31/50

MSS:

MSS SP-113, MSS SP-45

Material:

Ductile Iron

NSF:

NSF 372, NSF 61

NSF Certified:

Yes

Pressure - High:

250

Pressure Class:

125#

Style Name:

2500 Series

UL Listed:

Yes

Valve Body Style:

Open Right

Valve Bonnet Type:

Bolted

Valve Disc Material:

Ductile Iron

Valve Operator:

Operating Nut

Valve Port Opening:

Full Port

Valve Seat Material:

Metal

Valve Size:

24 in

Valve Stem:

Non-rising

Valve Type:

Resilient Wedge Gate Valve

Waterworks Application:

Water
