6 in. Stainless Steel Flanged Check Valve
Ames Fire & Waterworks
Series 1000SS 6 in. Stainless Steel Flanged Check Valve
Package Quantity Info:
Each: 1 Inner Pack: 1
Log in or Create Account
Log in or Create an Account to see product availability.
How to get it:
-
-
Shipping Not AvailableNot available at this time
Purchase history
Ames Fire & Waterworks
Series 1000SS
6 in. Stainless Steel Flanged Check Valve
0690837
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- Cost efficient design
- Minimal head loss
- Reduced water hammer
- Stainless steel disc
- Fugitive emission design
- Resilient and metal seats
- Long service life
- Standard port
-
Not Compliant, Approved for Non-Potable Water Applications
Specifications
- ANSI:
- ANSI B16.5 Class 125
- AWWA:
- AWWA C-207 Class D
- Collection:
- Series 1000SS
- End Connection 1:
- Flanged
- End Connection 2:
- Flanged
- End Connections:
- Flanged
- FM Approved:
- Yes
- Height:
- 13-1/2 in
- IAPMO Listed:
- No
- Installation Type:
- Horizontal Mount, Vertical Mount
- Lead Law Compliance Level:
- Not Compliant, Approved for Non-Potable Water Applications
- Length:
- 22-1/2 in
- Material:
- Stainless Steel, Bronze
- Maximum Temperature:
- 110
- Minimum Temperature:
- 33
- NSF Certified:
- Yes
- Pressure - High:
- 175
- Pressure Class:
- 125#
- Proposition 65:
- WARNING: This product can expose you to chemicals including lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
- Recommended Valve Application:
- Water
- UL Listed:
- UL 312
- UPC:
- 737733008798
- Valve Body Material:
- Stainless Steel
- Valve Body Style:
- Straight
- Valve Seat Material:
- Bronze
- Valve Size:
- 6 in
- Valve Type:
- Detector Check Valve
- Weight:
- 70 lb
- Width:
- 30 in
