3/4 in. Press x MNPT 316L Stainless Steel Adapter

Apollo® SmartPress

3/4 in. Press x MNPT 316L Stainless Steel Adapter

  • Fast #
  • Part #A123456936
  • Item #10054296
  • Manufacturer Part #123456936
3.2 out of 5 Customer Rating
Brand image
Apollo® SmartPress Press x MNPT Global 316L Stainless Steel Adapter
Apollo® SmartPress Press x MNPT Global 316L Stainless Steel Adapter
Apollo® SmartPress

3/4 in. Press x MNPT 316L Stainless Steel Adapter

  • Fast #
  • Part #A123456936
  • Item #10054296
  • Manufacturer Part #123456936
3.2 out of 5 Customer Rating
X Points

EACH
Pro Pricing Displays discounted prices List Pricing Displays catalog prices No Pricing Removes prices from page

View All Sizes

Package Quantity Info:

Each: 1 Inner Pack: 1
Looking for compatible parts?
Out of Stock
How to get it:
  • Pick Up   Not Available
    0  in  Leesburg, VA
    0 nearby
  • Shipping Not Available
    Not available at this time

All Sizes

Product Details

Product Description
  • Apollo SmartPress is an innovative press connection system designed for joining 1/2"-2" IPS ASTM A312 schedule 5/10s stainless steel pipe (approved for use with both AISI type 304/304L and 316/316L stainless)
  • The Apollo SmartPress product range consists of V-profile (type ASP) press fittings and valves produced from AISI 316L stainless steel alloy that are fitted with patented sealing elements for a guaranteed safe, leak-tight and lasting connection
  • The Apollo SmartPress system offers end-users a complete solution with maximum coverage of commercial and industrial applications requiring HNBR, EPDM, or FKM sealing elements
  • Complete range of AISI 316 fittings and valves
  • 500 psi operating pressure
  • Color-coded Visu-Control® foil for material/dimensions identification and visual press indication
  • Patented sealing element design with leak before Press® technology for added safety and optimized installation
  • Clear identification of sealing element and dimensions
  • Quick installation thanks to pre-marked insertion depth
  • Requires Certification
Dimensions & Measurements
End Connection 1
Press
End Connection 2
MNPT
End Connections
Press x MNPT
Fitting Size 1
3/4 in
Fitting Size 2
3/4 in
Fitting Sizes
3/4 in
Weight
0.289 lb
Characteristics & Features
Fitting Type
Adapter, Straight
Material
Stainless Steel, Rubber
Material Type
316L, EPDM
Electrical & Operational Information
Maximum Temperature
302
Warranty & Product Information
ANSI
ANSI 372, ANSI 61, ANSI Z1117
Application
Commercial, Compressed Air, Fire Sprinkler, Industrial, Instrument Air Supplies, Potable Water, Solar, Steam, Vacuum
ASME
ASME B31.1, ASME B31.3, ASME B31.9
ASTM
ASTM A-312, ASTM A-554
FM Approved
Yes
IAPMO Listed
Yes
NSF
NSF 372, NSF 61
NSF Certified
Yes
Origin
Global
UL Listed
UL 213
