3/4 in. 316 Stainless Steel Coupling - NO STOP P x

Apollo® SmartPress

SmartPress 3/4 in. 316 Stainless Steel Coupling - NO STOP P x

  • Fast #
  • Part #A123456930
  • Item #10054290
  • Manufacturer Part #123456930
3.6 out of 5 Customer Rating
Brand image
3/4 316 SS COUP - NO STOP P X P WITH EPDM SEALING ELEMENT
3/4 316 SS COUP - NO STOP P X P WITH EPDM SEALING ELEMENT
Apollo® SmartPress

SmartPress 3/4 in. 316 Stainless Steel Coupling - NO STOP P x

  • Fast #
  • Part #A123456930
  • Item #10054290
  • Manufacturer Part #123456930
3.6 out of 5 Customer Rating
X Points

Package Quantity Info:

Each: 1 Inner Pack: 1
Log in or Create an Account to see product availability.

Product Details

Product Details

  • Apollo SmartPress is an innovative press connection system designed for joining 1/2"-2"
  • IPS ASTM A312 schedule 5/10s stainless steel pipe (approved for use with both AISI type 304/304L and 316/316L stainless).
  • The Apollo SmartPress product range consists of V-profile (type ASP) press fittings and valves produced from AISI 316L stainless steel alloy that are fitted with patented sealing elements for a guaranteed safe, leak-tight and lasting connection.
  • The Apollo SmartPress system offers end-users a complete solution with maximum coverage of commercial and industrial applications requiring HNBR, EPDM, or FKM sealing elements
  • Complete range of AISI 316 fittings and valves500 psi operating pressure color-coded Visucontrol® foil for material/dimensions identification and visual press indication patented sealing element design with
  • Leak Before Pressed technology for added safety and optimized installation clear identification of sealing element and dimensions quick installation thanks to pre-marked insertion depth
  • Requires Certification

Documents

SPECIFICATION

Specifications

ANSI:
ANSI 372, ANSI 61 /ANSI/CAN Z1128
ASTM:
ASTM F3226/F3226M
Application:
Fire Protection, Industry, Commercial, Building
Collection:
SmartPress
End Connection 1:
Press
End Connection 2:
Press
End Connections:
Press
FM Approved:
Yes
Fitting Size 1:
3/4
Fitting Size 2:
3/4
Fitting Sizes:
3/4 in
Fitting Type:
Straight
Material:
Stainless Steel
Material Type:
316
Maximum Temperature:
212
NSF:
NSF 372, NSF61,
NSF Certified:
No
Origin:
Global
Pressure Class:
500 psi
Type:
A123456930
UL Listed:
No
