This product requires certification to purchase.

3 in Stainless Steel SAE Reduced Pressure Zone Assembly

Apollo Valves

RPLF4A Series 3 in Stainless Steel SAE Reduced Pressure Zone Assembly

  • Fast #
  • Part #A4ALF20002
  • Item #4385630
  • Manufacturer Part #4ALF20002
5 out of 5 Customer Rating
Brand image
Apollo Valves Stainless Steel Stainless Steel Flanged 350 psi Backflow Preventer
Apollo Valves Stainless Steel Stainless Steel Flanged 350 psi Backflow Preventer
Apollo Valves

RPLF4A Series 3 in Stainless Steel SAE Reduced Pressure Zone Assembly

  • Fast #
  • Part #A4ALF20002
  • Item #4385630
  • Manufacturer Part #4ALF20002
5 out of 5 Customer Rating
X Points

EACH
Pro Pricing Displays discounted prices List Pricing Displays catalog prices No Pricing Removes prices from page

Package Quantity Info:

Each: 1 Inner Pack: 1 Case: 1
Log in or Create an Account to see product availability.
How to get it:
  • Pick Up   Not Available
    0  in  Anaheim, CA
    0 nearby
    Pick Up  Not Available
    Not available in CA
  • Shipping Not Available
    Not available at this time
    Shipping Not Available
    Not available in CA

Product Details

Product Details

  • Domestic Stainless Steel Body: 2-1/2 in – 8 in
  • FDA Epoxy Coated Ductile Iron Body: 10 in & 12 in
  • Easy Maintenance – No Special Tools Required
  • Snap-In Check Retainers: 2-1/2 in – 6 in
  • Bolted-In Checks: 8 in – 12 in
  • Low Pressure loss as Documented by an Independent Laboratory
  • Center-Stem Guided TriForce™ Check Valves
  • Approved for Horizontal Flow
  • US Patents: 6,443,184; 7,025,085; 7,533,699; 8,240,333
  • Made in the USA – ARRA Compliant
  • Requires Certification

  • Lead Law Compliant

Specifications

ANSI:
ANSI 61, ANSI 372
ASSE Standards:
ASSE 1013
AWWA:
AWWA C-511
Automatic Shut-Off:
No
BAA Compliant:
Yes
CSA Certified:
CSA B64.4
Coating:
Epoxy
Collection:
RPLF4A Series
End Connection 1:
SAE
End Connection 2:
SAE
End Connections:
SAE
FM Approved:
No
Height:
22-3/5
IAPMO Listed:
Yes
Lead Law Compliance Level:
Lead Law Compliant and Certified
Lead Law Compliant:
Yes
Length:
28-1/2
Material:
Stainless Steel
Material Type:
304
Maximum Temperature:
140
Minimum Temperature:
33
NSF:
NSF 61, NSF 372
NSF Certified:
Yes
Number of Handles:
Two Handle
Pressure - Low:
0
Pressure - Maximum:
175 psi
Proposition 65:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Recommended Valve Application:
Potable Water
Temperature Range:
33 to 140 Deg F
UL Listed:
Yes
UPC:
670750671227
Valve Body Material:
Stainless Steel
Valve Material:
Stainless Steel
Valve Operator:
Wheel Handle
Valve Port Opening:
Standard Port
Valve Seat Material:
Chloramine-Resistant Silicone
Valve Size:
3 in
Valve Stem:
Blowout-proof
Valve Type:
Reduced Pressure Zone Assembly
Weight:
153
Width:
12
