3/4 in. 232F 250 psi Steam Trap
Armstrong International
200 Series 3/4 in. 232F 250 psi Steam Trap
Package Quantity Info:
Each: 1
Log in or Create Account
Log in or Create an Account to see product availability.
How to get it:
-
-
Shipping Not AvailableNot available at this time
Purchase history
Armstrong International
200 Series
3/4 in. 232F 250 psi Steam Trap
D501208
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- Cast iron for vertical installation
- For pressures to 250 psi (17 barg) . . .capacities to 20 000 lb/hr (9 072 kg/hr)
- The most reliable steam trap known-the inverted bucket-provides efficient condensate drainage of virtually all types of steam-using equipment
- A unique leverage system multiplies the force provided by the bucket to open the valve against system pressure
- The mechanism is free-floating and has no fixed pivots to create wear or friction
- Because the mechanism is located at the top of the trap, no dirt can collect on the orifice
- Small particles of dirt are held in suspension until discharged by the full differential purging action when the bucket sinks, pulling the valve off the seat
- The discharge orifice is surrounded by a water seal, which prevents live steam loss
- Automatic air venting is provided by a small vent hole in the bucket, which provides continuous automatic air and CO2 venting at steam temperature
- Inverted bucket traps drain continuously, although discharging intermittently, allowing no condensate backup
Specifications
- ASTM:
- ASTM A-48 Class 30
- Collection:
- 200 Series
- End Connection 1:
- NPT
- End Connection 2:
- NPT
- End Connections:
- NPT
- Height:
- 8-5/8 in
- Material:
- Cast Iron
- Maximum Temperature:
- 232
- Pressure - Maximum:
- 250 psig
- Pressure Class:
- 125#
- UL Listed:
- No
- Valve Body Material:
- Cast Iron
- Valve Disc Material:
- Stainless Steel
- Valve Seat Material:
- Hardened Chrome Steel
- Valve Size:
- 3/4 in
