15 Ton - Single-Packaged Rooftop Unit - Gas Heating - Low Heat - 208/230/3

Bryant

WeatherMaker® 15 Ton - Single-Packaged Rooftop Unit - Gas Heating - Low Heat - 208/230/3

  • Fast #
  • Part #C48FCDM16A2A50A0A0
  • Item #10290890
  • Manufacturer Part #48FCDM16A2A5-0A0A0
5 out of 5 Customer Rating
Brand image
15.0T LO HT G/E RTU PURON 208/230V
15.0T LO HT G/E RTU PURON 208/230V
Bryant

WeatherMaker® 15 Ton - Single-Packaged Rooftop Unit - Gas Heating - Low Heat - 208/230/3

  • Fast #
  • Part #C48FCDM16A2A50A0A0
  • Item #10290890
  • Manufacturer Part #48FCDM16A2A5-0A0A0
5 out of 5 Customer Rating
X Points

EACH
Pro Pricing Displays discounted prices List Pricing Displays catalog prices No Pricing Removes prices from page

Package Quantity Info:

Each: 1 Inner Pack: 1
Unavailable
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
Looking for compatible parts?
How to get it:
  • Pick Up   Not Available
    0  in  Hilliard, OH
    0 nearby
  • Shipping Not Available
    Not available at this time

Product Details

Product Details

  • HVAC equipment products sold to licensed contractors only. Products sold in select areas only, please contact your local branch for availability in your area.
  • New unit control board with intuitive, quick fan speed adjustment
  • New direct drive EcoBlue™ technology indoor fan system uses vane axial fan design and electronically commutated motor
  • Gas efficiencies up to 82%
  • Cooling operating range up to 115 Deg F and down to 40 Deg F using winter start kit
  • Innovative corrosive-resistant composite condensate pan in accordance with ASHRAE 62 Standard, sloping design, side or center drain
  • Exclusive IGC solid state control for on-board diagnostics with LED error code designation and burner control logic
  • Pre-painted exterior panels and primer-coated interior panels tested to 500 hr salt spray protection
  • New unit control board facilitating simple safety circuit troubleshooting and simplified control box arrangement as well as easy intuitive fan speed adjustment
  • Access panels with easy grip handles
  • Requires Certification

Documents

SPECIFICATION

Specifications

A2L Compatible:
No
BTU Cooling Rating:
174000 Btu/h
BTU Heat Rating:
180000 Btu/h
CFM:
5250 ft3/min
Coil Type:
Evaporator
Collection:
WeatherMaker®
Compressor Type:
Scroll
Decibel Rating (dB):
87 dB
Depth:
115 in
EER:
10.8
Factory Std. Refrigerant Charge:
384 oz
Height:
57 in
Horsepower:
1/4 hp
Max CFM:
5250 cfm
Phase:
Three Phase
Power Source:
Electric
Refrigerant:
R-410A
Refrigeration Control Type:
TXV
SEER:
14.5
Stages:
Two
Tonnage:
15 Ton
UL Listed:
Yes
Volts:
208/230V
Weight:
1408 lb
Width:
63 in
