6 in. Ductile Iron Flanged 500 psi 150# and 250# Backflow Preventer

FEBCO

LF800 Series 6 in. Ductile Iron Flanged 500 psi 150# and 250# Backflow Preventer

  • Fast #
  • Part #FLF800GPMLADWPU
  • Item #10080053
  • Manufacturer Part #88006233
5 out of 5 Customer Rating
Brand image
FEBCO Ductile Iron Flanged 500 psi 150# and 250# Backflow Preventer
FEBCO Ductile Iron Flanged 500 psi 150# and 250# Backflow Preventer
null
FEBCO

LF800 Series 6 in. Ductile Iron Flanged 500 psi 150# and 250# Backflow Preventer

  • Fast #
  • Part #FLF800GPMLADWPU
  • Item #10080053
  • Manufacturer Part #88006233
5 out of 5 Customer Rating
X Points

EACH
Pro Pricing Displays discounted prices List Pricing Displays catalog prices No Pricing Removes prices from page

Package Quantity Info:

Each: 1 Inner Pack: 1
Unavailable
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
Looking for compatible parts?
How to get it:
  • Pick Up   Not Available
    0  in  Hilliard, OH
    0 nearby
  • Shipping Not Available
    Not available at this time

Product Details

Product Details

  • Ductile iron body epoxy coated using ArmorTek corrosion resistant technology
  • Spring loaded swing check
  • Detector bypass assembly
  • 250 psi pressure rating
  • Advanced ArmorTek™ coating technology to resist corrosion of internals
  • Simple service procedures
  • Cast lifting ring for ease of installation
  • Available in sizes 4", 6", 8", and 10"
  • Standard bypass size 3/4"; optional size 1"
  • End connections - flanged ANSI B16.42, class 150
  • Requires Certification

  • Lead Law Compliant

Specifications

ANSI:
ANSI 61 Annex G, ANSI B16.42
ASTM:
ASTM A-536 Grade 65-45-12
AWWA:
AWWA C-550 1990
Coating:
Fusion Bonded Epoxy
Collection:
LF800 Series
End Connection 1:
Flanged
End Connection 2:
Flanged
End Connections:
Flanged
FM Approved:
Yes
Height:
21 in
Included:
Water Meter
Installation Type:
Horizontal, Vertical
Lead Law Compliance Level:
Lead Law Compliant and Certified
Lead Law Compliant:
Yes
Material:
Ductile Iron
Maximum Temperature:
110
Minimum Temperature:
32
NSF:
NSF 61 Annex G
NSF Certified:
Yes
Pressure - High:
250
Pressure - Maximum:
500 psi
Pressure Class:
150#, 250#
Proposition 65:
CALIFORNIA PROP 65 WARNING: This product can expose you to chemicals including lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Recommended Valve Application:
Gas, Oil, Water
Temperature Range:
32 to 110 Deg F (0 to 43 Deg C)
UL Listed:
Yes
UPC:
643925539097
Valve Body Material:
Ductile Iron
Valve Body Style:
Straight
Valve Disc Material:
Ductile Iron
Valve Seat Material:
Stainless Steel
Valve Size:
6 in
Valve Type:
Check Valve
Weight:
157 lb
