3/4 in. Carbon Steel Standard Port Threaded 2000# Ball Valve

Flow-Tek

S90 Series 3/4 in. Carbon Steel Standard Port Threaded 2000# Ball Valve

  • Fast #
  • Part #FS90043RRL
  • Item #7034672
  • Manufacturer Part #S90-04-3-R-R-L
5 out of 5 Customer Rating
Brand image
Flow-Tek Carbon Steel Standard Port Threaded 2000# Ball Valve
Flow-Tek Carbon Steel Standard Port Threaded 2000# Ball Valve
Flow-Tek

S90 Series 3/4 in. Carbon Steel Standard Port Threaded 2000# Ball Valve

  • Fast #
  • Part #FS90043RRL
  • Item #7034672
  • Manufacturer Part #S90-04-3-R-R-L
5 out of 5 Customer Rating
X Points

EACH
Pro Pricing Displays discounted prices List Pricing Displays catalog prices No Pricing Removes prices from page

Package Quantity Info:

Each: 1 Inner Pack: 1
Unavailable
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
Looking for compatible parts?
How to get it:
  • Pick Up   Not Available
    0  in  Hilliard, OH
    0 nearby
    Pick Up  Not Available
    Not available in OH
  • Shipping Not Available
    Not available at this time
    Shipping Not Available
    Not available in OH

Product Details

Product Details

  • Flow-Tek's Series S70 and Series S90 threaded ball valvesare an economical solution from the Bray product line for high pressure applications in the process industries
  • Standard two piece valve bodies are available in Stainless Steel or Carbon Steel
  • Stainless Steel bodies are investment cast and solution annealed for the highest quality and added strength
  • Cast Carbon Steel bodies are normalized and black phosphate coated for added corrosion resistance
  • All body castings are marked with a foundry heat number for full traceability
  • These quarter turn valves feature an adjustable packing gland for secure sealing
  • All Series S70/Series S90 valves comply with MSS-SP 72
  • All valves are tested in accordance with MSS-SP 72
  • Vacuum Service to 29 inches Hg gauge
  • Requires Certification

Documents

SPECIFICATION

Specifications

ASTM:
ASTM A-216 Grade WCB, ASTM A-351 Grade CF8M, ASTM A-479 Type 316, ASTM A-351 Type 316
Collection:
S90 Series
End Connection 1:
Threaded
End Connection 2:
Threaded
End Connections:
Threaded
FM Approved:
No
Handle Material:
304 Stainless Steel
Height:
2-9/25 in
IAPMO Listed:
No
Length:
2-4/5 in
MSS:
MSS SP-72
Material:
Carbon Steel
Maximum Temperature:
450
Minimum Temperature:
-20
NSF Certified:
No
Pressure - High:
2000
Pressure Class:
2000#
Recommended Valve Application:
Air, Water, Oil, Gas, General Service
Temperature Range:
-20 to 450 Deg F (-29 to 232 Deg C)
UL Listed:
No
Valve Body Style:
2 piece
Valve Disc Material:
Stainless Steel
Valve Operator:
Latch Locking Lever Handle
Valve Port Opening:
Standard Port
Valve Seat Material:
RTFE
Valve Size:
3/4 in
Valve Stem:
Blowout-proof
Valve Type:
Ball Valve
Weight:
1.10 lb
