2-1/2 in. Ductile Iron Flanged Gate Valve
FNW®
Figure 751 2-1/2 in. Ductile Iron Flanged Gate Valve
Package Quantity Info:
Each: 1 Inner Pack: 1 Pallet: 25Quantity:
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
-
Shipping AvailableAvailable for immediate shipment
Purchase history
FNW®
Figure 751
2-1/2 in. Ductile Iron Flanged Gate Valve
FNW751L
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- 300 PSI non-shock cold working pressure
- 32°-175°F temperature range
- Ductile iron body and bonnet
- 304 stainless steel stem
- EPDM encapsulated ductile iron disc
- Outside yoke & stem
- Pre-tapped and plugged for bypass
- Pre-grooved stem for tamper switch
Dimensions & Measurements
End Connection 1
Flanged
End Connection 2
Flanged
End Connections
Flanged
Length
7-12/25 in
Pressure Class
150#
Valve Size
2-1/2 in
Characteristics & Features
Coating
Fusion Bonded Epoxy
Collection
Figure 751
Handle Material
Ductile Iron
Material
Ductile Iron
Valve Body Material
Ductile Iron
Valve Body Style
2 piece
Valve Bonnet Type
Bolted
Valve Disc Material
EPDM
Valve Operator
Handwheel
Valve Stem
Pre-Grooved
Valve Type
Gate Valve
Electrical & Operational Information
Maximum Temperature
175
Pressure - High
300
Warranty & Product Information
ANSI
ANSI 61, ANSI C550
ASME
ASME B16.42
ASTM
ASTM A536, ASTM D-2000
AWWA
AWWA C-515, AWWA C-550
FM Approved
Yes
NSF
NSF 61, NSF 372
NSF Certified
Yes
Recommended Valve Application
Cold Working Pressure
UL Listed
Yes
UPC
781889357361
