1/2 in. Brass Full Port FPT 600# Ball Valve
FNW®
Figure X440 1/2 in. Brass Full Port FPT 600# Ball Valve
Package Quantity Info:
Each: 1 Inner Pack: 1
How to get it:
-
Pick Up Not AvailableNot available in OH
-
Shipping Not AvailableNot available at this timeShipping Not AvailableNot available in OH
Purchase history
FNW®
Figure X440
1/2 in. Brass Full Port FPT 600# Ball Valve
X440D
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- 1/2 in. brass ball valve
- End Connections: Threaded
- Valve Length: 2.64 in.
- Valve Pressure Class: 600#
- Recommended Application: Water, oil, gas
- NSF 372, NSF 61G
- ANSI B1.20.1
- Blow-out Proof Stem
- Double Viton® O-ring Stem Seal with additional PTFE Seal
-
Lead Law Compliant
Specifications
- ANSI:
- ANSI B1.20.1, ANSI 61, ANSI 372
- Clean Bagged:
- No
- Collection:
- Figure X440
- End Connection 1:
- FPT
- End Connection 2:
- FPT
- End Connections:
- FPT
- FM Approved:
- No
- IAPMO Listed:
- No
- ISO:
- ISO 5211
- Lead Law Compliance Level:
- Lead Law Compliant and Certified
- Lead Law Compliant:
- Yes
- Length:
- 2-2/3
- MSS:
- MSS SP-110
- Material:
- Brass
- NSF:
- NSF 61G, NSF 372, NSF 61
- NSF Certified:
- Yes
- Pressure - High:
- 600
- Pressure - Maximum:
- 600 psi
- Pressure Class:
- 600#
- Recommended Valve Application:
- Potable Water
- UL Listed:
- Yes
- Valve Body Material:
- Forged Brass
- Valve Body Style:
- 2 piece
- Valve Operator:
- Lever Handle
- Valve Port Opening:
- Full Port
- Valve Seat Material:
- PTFE
- Valve Size:
- 1/2 in
- Valve Stem:
- Blowout-proof
- Valve Type:
- Ball Valve
