5 Ton - 2 Stage - Commercial Packaged Gas/Electric Unit - 208/230V - 3 Phase - R-410A
Friedrich Air Conditioning
Renaissance RGECZR Series 5 Ton - 2 Stage - Commercial Packaged Gas/Electric Unit - 208/230V - 3 Phase - R-410A
Points
Package Quantity Info:
Each: 1 Inner Pack: 1
Log in or Create Account
Log in or Create an Account to see product availability.
Purchase history
Friedrich Air Conditioning
Renaissance RGECZR Series
5 Ton - 2 Stage - Commercial Packaged Gas/Electric Unit - 208/230V - 3 Phase - R-410A
RGECZR060ACT12BAC
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- HVAC equipment products sold to licensed contractors only. Products sold in select areas only, please contact your local branch for availability in your area.
- Factory charged with R-410A HFC refrigerant
- Wired and run tested
- Scroll compressor with internal line break overload and high-pressure protection
- Convertible airflow - vertical down flow or horizontal side flow
- Forkable base rails for easy handling and lifting
- Cooling operation up to 125 Deg F ambient
- Microchannel evaporator and condenser coil
- Overflow condensate sensor
- PlusOne® diagnostics with dual 7-segment LED display to meet code compliance
Specifications
- A2L Compatible:
- No
- Application:
- Commercial
- BTU:
- 125000
- BTU Cooling Rating:
- 60000 Btu/h
- BTU Heat Rating:
- 125000 Btu/h
- Blower Type:
- Direct Drive
- CEC Compliant:
- For Sale in CA
- CFM:
- 2000
- Coil Type:
- Micro-channel
- Collection:
- Renaissance RGECZR Series
- Compressor Stages:
- Single Stage
- Compressor Type:
- Scroll
- Configuration:
- Convertible
- Decibel Rating (dB):
- 83.3 dB
- Depth:
- 46-3/4
- EER:
- 11.2
- Factory Std. Refrigerant Charge:
- 82
- Gas Connection Size:
- 3/4
- Height:
- 41-3/8
- Horsepower:
- 0.5 hp
- IEER:
- 14
- IEER Range:
- 14.0 - 99.9
- Ignition System:
- Direct Spark Ignition
- Input (MBH):
- 124 MBH
- Length:
- 46-3/4
- MBH:
- 124
- Max CFM:
- 5900
- Maximum Overcurrent Protection (MOP):
- 45
- Minimum Circuit Ampacity (MCA):
- 30
- Number of Compressors:
- 1
- Number of Condenser Fan Motors:
- 1
- Phase:
- Three Phase
- Power Source:
- Electric, Gas
- RPM:
- 1075
- Refrigerant:
- R-410A
- Refrigeration Control Type:
- TXV
- SEER:
- 14.0
- SEER2:
- 16.2
- SEER2 Range:
- 15.2 - 40.0
- Stages:
- Single
- Tonnage:
- 5 Ton
- Type:
- FRGECZR060ACT12BAC
- Volts:
- 208/230V
- Watts:
- 17.58
- Weight:
- 583
- Width:
- 79-1/4
