1/4 in. Brass Full Port Threaded Ball Valve

Jomar International

JF-100T 1/4 in. Brass Full Port Threaded Ball Valve

  • Fast #
  • Part #J100101LH
  • Item #7568946
  • Manufacturer Part #100-101-LH
3.2 out of 5 Customer Rating
Brand image
Jomar International Brass Full Port Threaded Ball Valve
Jomar International Brass Full Port Threaded Ball Valve
Jomar International

JF-100T 1/4 in. Brass Full Port Threaded Ball Valve

  • Fast #
  • Part #J100101LH
  • Item #7568946
  • Manufacturer Part #100-101-LH
3.2 out of 5 Customer Rating
X Points

EACH
Pro Pricing Displays discounted prices List Pricing Displays catalog prices No Pricing Removes prices from page

Package Quantity Info:

Each: 1 Inner Pack: 1
Looking for compatible parts?
Out of Stock
How to get it:
  • Pick Up   Not Available
    0  in  Hilliard, OH
    0 nearby
  • Shipping Not Available
    Not available at this time

Product Details

Product Details

  • Gland follower and single O-ring stem design
  • Blow-out proof stem
  • Latch lock handle
  • 100% leak tested
  • Requires Certification

Documents

SPECIFICATION

Specifications

ANSI:
ANSI B1.20.1, ANSI Z21.15
ASME:
ASME B16.33, ASME B16.38, ASME B16.44
CSA Certified:
CSA CGA 3.16
Clean Bagged:
No
Collection:
JF-100T
End Connection 1:
NPT
End Connection 2:
NPT
End Connections:
NPT
FM Approved:
Yes
Handle Material:
Steel
IAPMO Listed:
No
Length:
1-73/100 in
MSS:
MSS SP-110
Maximum Temperature:
300
NSF Certified:
No
Pressure - High:
600
Pressure Class:
600#
UL Listed:
Yes
UPC:
662527294197
Valve Body Material:
Brass
Valve Body Style:
2 piece
Valve Operator:
Latch Locking Lever Handle
Valve Port Opening:
Full Port
Valve Seat Material:
PTFE
Valve Size:
1/4 in
Valve Stem:
Blowout-proof
Valve Type:
Ball Valve
