3 in. Brass Full Port Threaded 400# Ball Valve
Jomar International
T-100NE 3 in. Brass Full Port Threaded 400# Ball Valve
Package Quantity Info:
Each: 1 Inner Pack: 1
Unavailable
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
-
Shipping Not AvailableNot available at this time
Purchase history
Jomar International
T-100NE
3 in. Brass Full Port Threaded 400# Ball Valve
100-710
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- Manufactured with Hostaflon®-TFM 1600 seats and stem packing designed for steam applications up to 366° F
- Temperature range: -40° F to 366° F
- Double Viton® stem O-rings
- 100% made in Italy
- Leak proof stem - lifetime warranty
- 29 in-hg vacuum rating
- 100% leak tested
- Triple sealing stem with 2 FKM O-rings and second generation PTFE seal
- Blow-out proof stem
Specifications
- ANSI:
- ANSI B1.20.1, ANSI Z21.15
- ASME:
- ASME B16.33, ASME B16.38
- CSA Certified:
- CSA 3.16
- Clean Bagged:
- No
- Collection:
- T-100NE
- End Connection 1:
- NPT
- End Connection 2:
- NPT
- End Connections:
- NPT
- FM Approved:
- Yes
- Fire Suppression System Rated:
- No
- Handle Material:
- Steel
- IAPMO Listed:
- No
- Length:
- 7-2/25 in
- MA Approved:
- No
- MSS:
- MSS SP-110
- Material:
- Brass
- Maximum Temperature:
- 366
- NSF:
- NSF 61-8
- NSF Certified:
- Yes
- Pressure - High:
- 400, 150
- Pressure Class:
- 400#
- Recommended Valve Application:
- Gas, Oil, Water
- UL Listed:
- Yes
- UPC:
- 662527290991
- Valve Body Style:
- 2 piece
- Valve Operator:
- Lever Handle
- Valve Port Opening:
- Full Port
- Valve Seat Material:
- PTFE
- Valve Size:
- 3 in
- Valve Stem:
- Blowout-proof
- Valve Type:
- Ball Valve
- cUPC Certified:
- No
