5/8 x 3/4 in. Bronze Body, Multi-Jet, Cubic Feet, Plastic Bottom, AccuLinx Encoder Register with 5' Itron Connector
Master Meter
5/8 x 3/4 in. Bronze Body, Multi-Jet, Cubic Feet, Plastic Bottom, AccuLinx Encoder Register with 5' Itron Connector
Package Quantity Info:
Each: 1 Inner Pack: 1
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
Pick Up Not AvailableNot available in 'OH'
-
Shipping Not AvailableNot available at this timeShipping Not AvailableNot available in 'OH'
Purchase history
Master Meter
5/8 x 3/4 in. Bronze Body, Multi-Jet, Cubic Feet, Plastic Bottom, AccuLinx Encoder Register with 5' Itron Connector
B12-A11-B05-0102A-1
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- Rugged basket strainer built from advanced polymer materials for superior wear mitigation
- Proprietary design produces smooth, laminar flow profile for improved accuracy
- Award-winning DIALOG 3G register design houses all vital components - encoder, RF transmitter, battery and antennae - safely within the register's stainless steel and tempered glass enclosure
- Free of external wires, components and connections - the #1 cause of field related issues on competitive designs
- Assures compliance with the Safe Drinking Water Act (SDWA)
- Measures with only one moving part that is hydro dynamically balanced on a sapphire bearing to preserve accuracy and promote a positive bottom line
- Exceptional performance in passing entrained solids and operating in environments with high mineral content
- Clean, elegant measurement design is highly sensitive to leaks and low flow while limiting wear for excellent revenue protection
-
Lead Law Compliant
Documents
Specifications
- ANSI:
- ANSI 372, ANSI 61
- AWWA:
- AWWA C-708
- End Connection 1:
- Mechanical Joint
- End Connection 2:
- Mechanical Joint
- End Connections:
- Mechanical Joint
- Fitting Size 1:
- 5/8
- Fitting Size 2:
- 3/4
- Fitting Sizes:
- 5/8 in x 3/4 in
- Lead Law Compliance Level:
- Lead Law Compliant and Certified
- Lead Law Compliant:
- Yes
- Length:
- 7-1/2
- Material:
- Plastic
- NSF:
- NSF 372, NSF 61
- NSF Certified:
- Yes
- Product Type:
- Multijet
- UL Listed:
- No
- Waterworks Application:
- Water
- Weight:
- 3.95
- Width:
- 3-5/8
