10 in. Mechanical Joint x Flanged Cast Iron Non-Rising Stem Resilient Wedge Gate Valves (Less Accessories)
Matco-Norca
10 in. Mechanical Joint x Flanged Cast Iron Non-Rising Stem Resilient Wedge Gate Valves (Less Accessories)
Package Quantity Info:
Each: 1 Inner Pack: 1
Unavailable
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
-
Shipping Not AvailableNot available at this time
Purchase history
Matco-Norca
10 in. Mechanical Joint x Flanged Cast Iron Non-Rising Stem Resilient Wedge Gate Valves (Less Accessories)
200FJ15W
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- Non-Rising Stem
- All Cast Iron Construction
- Valves have fusion bonded epoxy coated housings
- Stainless Steel Stem, Bonnet and bolts
- Buna-N encapsulated Resilient wedge
Specifications
- ANSI:
- ANSI B16.1 Class 125
- AWWA:
- AWWA C-515
- Coating:
- Epoxy
- End Connection 1:
- Flanged
- End Connection 2:
- Mechanical Joint
- End Connections:
- Flanged x Mechanical Joint
- FM Approved:
- No
- Length:
- 13 in
- Material:
- Cast Iron, Stainless Steel
- Maximum Temperature:
- 140
- NSF Certified:
- No
- UL Listed:
- No
- Valve Disc Material:
- Ductile Iron
- Valve Operator:
- 2 in operating nut
- Valve Port Opening:
- Full Port
- Valve Seat Material:
- Buna-N
- Valve Size:
- 10 in
- Valve Stem:
- Non-rising
- Valve Type:
- Gate Valve
