Floor Mount Tub Filler Riser Leg in Brushed Nickel
You last purchased this on
Moen
Weymouth™ Floor Mount Tub Filler Riser Leg in Brushed Nickel
Purchase history
Moen
Weymouth™
Floor Mount Tub Filler Riser Leg in Brushed Nickel
TS25105BN
Order #
Order Date
Job Name
My PO#
Frequently Purchased Together
Product Details
Product Details
- Integrated M-CORE Transfer Valves can control 2 or 3 showering devices, a simple transfer cartridge modification changes the valve’s flow from two outlets to three outlets
- When using 2 showering devices, the valve has 2 independent and 1 shared functions
- When using 3 showering devices, the valve has 3 independent and 3 shared functions
- IMPORTANT: When using 3 Showering Devices, transfer valve cartridge must be modified. Simple Cartridge Modification changes the valves flow from two outlets to three outlets. See Transfer Valve Instructions for additional information.
- IMPORTANT: When using 2 Showering Devices, designated outlet 3 must be CAPPED. Caps are not included with the transfer valves.
- M-CORE valves, with 3-Series trim, have pressure-balancing capabilities designed to control temperature fluctuations in the event of water pressure changes in the home
- Features volume control, allowing you to adjust the flow of water forgreater functionality
- Improved style options, including the perfectly matched mixing and transfer trim, are available
- Offers design flexibility to choose your trim after the valve installation, so you can take your time with your style and finish selections
- M-CORE’S adaptability allows the valves to be roughed in with the option of functionality and style changes that don't require removing or changing the valve(s)
Specifications
- ANSI:
- ANSI A112.18.1
- ASME:
- ASME A112.18.1
- BAA Compliant:
- Yes
- CSA Certified:
- CSA B125.1
- Color Finish Name:
- Brushed Nickel
- End Connection 1:
- Male
- End Connections:
- Male
- Fitting Size 1:
- 3/4 in
- Fitting Sizes:
- 3/4 in
- Material:
- Metal
- Maximum Temperature:
- 160
- Pressure - Maximum:
- 100 psi
