1-1/2 in. Cast Iron Flanged End Basket Type Strainer
You last purchased this on
Mueller Steam Specialty
Model 125 1-1/2 in. Cast Iron Flanged End Basket Type Strainer
Log in or Create Account
Log in or Create an Account to see product availability.
-
Pick Up: Not available
-
Shipping: Not available
Purchase history
Mueller Steam Specialty
Model 125
1-1/2 in. Cast Iron Flanged End Basket Type Strainer
M6700704
Order #
Order Date
Job Name
My PO#
Frequently Purchased Together
Product Details
- Cast iron
- Threaded
- 0.062 perf screen
- Machined basket seat eliminates particle bypass
- Cover is secured with quick-opening knobs to minimize service time
- O-ring seals on both the cover and baskets can usually be re-used after service, no need to clean gasket residue and replace costly gaskets
- Designed for large capacity straining and ease of maintenance
- Class 125
Specifications
- ADA Compliant:
- No
- ASTM:
- ASTM A-126 Class B
- Application:
- Commercial, Industrial
- BAA Compliant:
- No
- Collection:
- Model 125
- Cover Material:
- Cast Iron
- Depth:
- 6-1/2 in
- End Connection 1:
- NPT
- End Connection 2:
- NPT
- End Connections:
- NPT
- Fitting Size 1:
- 1-1/2 in
- Fitting Size 2:
- 1-1/2 in
- Fitting Sizes:
- 1-1/2 in
- Height:
- 9-1/2 in
- Lead Law Compliance Level:
- Applicable to Lead Leaching, Not Compliant
- Length:
- 6-5/16 in
- Material:
- Cast Iron, Rubber, Stainless Steel
- Material Type:
- Buna-N, 304
- Maximum Temperature:
- 300
- Minimum Temperature:
- -20
- Origin:
- Domestic
- Perforation Size:
- 1/16 in
- Pressure - High:
- 200
- Pressure Class:
- 125#, 165#, 200#
- Recommended Valve Application:
- Gas, Oil, Steam, Water
- Strainer Type:
- Basket
- UL Listed:
- No
- Valve Body Material:
- Cast Iron
- Valve Body Style:
- Basket
- Weight:
- 12.5 lb
- Width:
- 3-1/2 in
