3/4 in. Carbon Steel Standard Port NPT CL800 Fire-Tite Ball Valve w/PTFE Seats
Neles Controls (Brand of Metso)
Series 4000 3/4 in. Carbon Steel Standard Port NPT CL800 Fire-Tite Ball Valve w/PTFE Seats
Package Quantity Info:
Each: 1
How to get it:
-
-
Shipping Not AvailableNot available at this time
Purchase history
Neles Controls (Brand of Metso)
Series 4000
3/4 in. Carbon Steel Standard Port NPT CL800 Fire-Tite Ball Valve w/PTFE Seats
MA0005355
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Dimensions & Measurements
End Connection 1
NPT
End Connection 2
NPT
End Connections
NPT
Length
3-1/100 in
Pressure Class
800#
Valve Size
3/4 in
Weight
2.7 lb
Characteristics & Features
Clean Bagged
No
Collection
Series 4000
Handle Material
Zinc Plated Carbon Steel
Material
Carbon Steel, Stainless Steel
Material Type
316
Valve Body Material
Carbon Steel
Valve Body Style
3 piece
Valve Operator
Locking Lever Handle
Valve Port Opening
Standard Port
Valve Seat Material
PTFE
Valve Stem
Extension
Valve Type
Ball Valve
Electrical & Operational Information
Pressure - High
2500
Temperature Range
-20 to 500 Deg F (-29 to 260 Deg C)
Warranty & Product Information
API
API 598, API 607, API 608
ASME
ASME B1.20.1, ASME B15.34, ASME B16.11, ASME B16.25, ASME B31.1, ASME B31.3, ASME B31.4
ASTM
ASTM A-193 Grade B7, ASTM A-194 Grade 2H, ASTM A-216 Grade WCB, ASTM A-351 Type CF8M
FM Approved
No
IAPMO Listed
No
ISO
ISO 17292, ISO 5211, ISO 7-1
MSS
MSS SP-25, MSS SP-55, MSS SP-72
NSF Certified
No
UL Listed
No
