2 in. Plastic Socket Weld 150# Ball Valve
NIBCO
4770 2 in. Plastic Socket Weld 150# Ball Valve
Package Quantity Info:
Each: 1 Inner Pack: 1 Case: 4 Pallet: 540
How to get it:
-
-
Shipping Not AvailableNot available at this time
Purchase history
NIBCO
4770
2 in. Plastic Socket Weld 150# Ball Valve
MB0012D
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- Individually packaged and labeled
- Socket ends per ASTM 2846
- NSF/ANSI 61-G Certified
- Packaged in recyclable heavy duty poly bags
- Kit can be marked and tagged per contractor requirements
- Use in U.S. drinking water applications is prohibited after January 3, 2014
Specifications
- ANSI:
- ANSI 61
- ASTM:
- ASTM D-2846
- Clean Bagged:
- No
- Collection:
- 4770
- End Connection 1:
- Socket Weld
- End Connection 2:
- Socket Weld
- End Connections:
- Socket Weld
- FM Approved:
- No
- Handle Material:
- ABS
- Height:
- 3-7/10 in
- IAPMO Listed:
- No
- Length:
- 5-69/100 in
- MSS:
- MSS SP-72
- Material:
- Plastic
- Material Type:
- CPVC
- Maximum Temperature:
- 73
- NSF:
- NSF 61
- NSF Certified:
- Yes
- Pressure - Maximum:
- 150 psi
- Pressure Class:
- 150#
- Proposition 65:
- WARNING: Cancer - www.P65Warnings.ca.gov
- Recommended Valve Application:
- Cold Water, Commercial, Hot Water, Residential
- Temperature Range:
- Up to 140 Deg F
- UL Listed:
- No
- UPC:
- 039923331939
- Valve Body Style:
- 1 piece
- Valve Operator:
- T-Handle
- Valve Seat Material:
- PTFE
- Valve Size:
- 2 in
- Valve Type:
- Ball Valve
- Weight:
- 1.102 lb
