3 in. Carbon Steel RPTFE Locking Lever Handle Butterfly Valve
NIBCO
LCS-7822 Series 3 in. Carbon Steel RPTFE Locking Lever Handle Butterfly Valve
Purchase history
NIBCO
LCS-7822 Series
3 in. Carbon Steel RPTFE Locking Lever Handle Butterfly Valve
NLL213F
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- API 609 seat pressure/temperature ratings
- ISO 5211 actuation mounting
- PTFE seats and seals
- 600 psi/41.4 bar non-shock cold working pressure
- Valve pressure rating 740 psi
- Maximum operating temperature 400°F at 100 psi
- Lug style
- Blowout-proof stem
- Stainless steel disc and stem
- Integrally cast disc stop
Dimensions & Measurements
End Connection 1
Lug
End Connection 2
Lug
End Connections
Lug
Length
4-3/20 in
Pressure Class
300#, 740#
Valve Size
3 in
Characteristics & Features
Coating
Epoxy Powder
Collection
LCS-7822 Series
Material
Carbon Steel, Plastic, Stainless Steel
Material Type
RPTFE
Proposition 65
WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
Valve Body Material
Carbon Steel
Valve Body Style
Lug
Valve Bonnet Type
Welded
Valve Disc Material
Stainless Steel
Valve Operator
Locking Lever Handle
Valve Seat Material
15% Glass Filled RPTFE
Valve Stem
Blowout-Proof
Valve Type
Butterfly Valve
Electrical & Operational Information
Maximum Temperature
400
Warranty & Product Information
ANSI
ANSI B16.34A, ANSI B16.5, ANSI 300, ANSI 61
API
API 609
ASME
ASME B16.34A, ASME B16.5
ASTM
ASTM A108 Grade 1045, ASTM A216 Grade WCB, ASTM A240 S31600, ASTM A276 S31600, ASTM A351 Grade CF8M, ASTM A564 S17400
FM Approved
No
ISO
ISO 5211
MSS
MSS SP-25, MSS SP-68
NSF
NSF 61
NSF Certified
Yes
Origin
Domestic
Recommended Valve Application
Compressed Air, Glycol, Hot Water, Steam
UL Listed
No
UPC
039923315274
