1-1/2 in. DZR Bronze Full Port Press 250# Ball Valve
NIBCO
PC-585-70-66 1-1/2 in. DZR Bronze Full Port Press 250# Ball Valve
Package Quantity Info:
Each: 1 Inner Pack: 3 Case: 6 Pallet: 252
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
-
Shipping AvailableAvailable for immediate shipment
Purchase history
NIBCO
PC-585-70-66
1-1/2 in. DZR Bronze Full Port Press 250# Ball Valve
NF84HCC
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- Valve pressure rating 250 psi/17.2 bar non-shock cold working pressure
- Maximum service temperature 250°F
- Two-piece body
- Full port
- Stainless steel trim
- Blowout-proof stem
- Vented ball
- Reinforced PTFE seat rings
- Press x press female end connections
- Press leak-detection feature
Specifications
- ASTM:
- ASTM A-276, ASTM B-16, ASTM B-584, ASTM B75
- Clean Bagged:
- No
- Collection:
- PC-585-70-66
- End Connection 1:
- Press
- End Connection 2:
- Press
- End Connections:
- Press
- Handle Material:
- Zinc Plated Steel
- Height:
- 2-19/20 in
- Length:
- 10-18/25 in
- MSS:
- MSS SP-110
- Material:
- Bronze
- Material Type:
- C84400
- Maximum Temperature:
- 250
- Minimum Temperature:
- -20
- Origin:
- Domestic
- Pressure - High:
- 250
- Pressure - Maximum:
- 250 psi
- Pressure Class:
- 250#
- Proposition 65:
- WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
- Recommended Valve Application:
- Sprinkler Systems, Commercial, Plumbing, Heating, HVAC, Industrial, Irrigation, Residential
- Temperature Range:
- -20 to 250 Deg F
- UPC:
- 039923348388
- Valve Body Material:
- Bronze
- Valve Body Style:
- Ball
- Valve Disc Material:
- Stainless Steel
- Valve Operator:
- Lever Handle
- Valve Port Opening:
- Full Port
- Valve Seat Material:
- Reinforced PTFE
- Valve Size:
- 1-1/2 in
- Valve Stem:
- Blowout-proof
- Valve Type:
- Ball Valve
- Weight:
- 5.596 lb
- Width:
- 4-3/4 in
- cUPC Certified:
- No
