1 in. DZR Copper Alloy Press 250# Ball Valve
NIBCO
PC-FP-600A-D-LF 1 in. DZR Copper Alloy Press 250# Ball Valve
Package Quantity Info:
Each: 1 Inner Pack: 6 Case: 24 Pallet: 768Quantity:
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
-
Shipping AvailableAvailable for immediate shipment
Purchase history
NIBCO
PC-FP-600A-D-LF
1 in. DZR Copper Alloy Press 250# Ball Valve
NF99KDA
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- Valve pressure rating 250 psi/17.2 bar non-shock cold working pressure
- Maximum service temperature 250°F
- Copper-to-copper connections
- Press x press female end connections
- Full-port
- Blow-out proof stem
- Reinforced PTFE seat rings
- Multiple handle options
- Press leak-detection feature
- Dezincification resistant
Product Information
-
Lead Law Compliant
Dimensions & Measurements
End Connection 1
Press
End Connection 2
Press
End Connections
Press
Length
4-21/50 in
Pressure Class
225#, 250#
Valve Size
1 in
Weight
1.26 lb
Characteristics & Features
Collection
PC-FP-600A-D-LF
Handle Material
Steel
Material
Copper Alloy, Brass, Plastic, Steel
Material Type
C46500, DZR, PTFE
Proposition 65
WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
Valve Body Material
Copper Alloy
Valve Body Style
2 piece
Valve Operator
Lever Handle
Valve Port Opening
Full Port
Valve Seat Material
PTFE
Valve Stem
Blowout-Proof
Valve Type
Ball Valve
Warranty & Product Information
ANSI
ANSI 372, ANSI 61, ANSI Z1157
ASME
ASME B16.51
ASTM
ASTM B-88, ASTM D-2000
IAPMO Listed
Yes
Lead Law Compliance Level
Lead Law Compliant and Certified
Lead Law Compliant
Yes
MSS
MSS SP-110, MSS SP-145
NSF
NSF 372, NSF 61
NSF Certified
Yes
Origin
Global
Recommended Valve Application
Cold Water, Hot Water
UPC
039923414953
