1/2 in. Silicon Bronze Full Port Female Solder 600# Ball Valve
NIBCO
S-685-66-LF 1/2 in. Silicon Bronze Full Port Female Solder 600# Ball Valve
Package Quantity Info:
Each: 1 Inner Pack: 8 Case: 80 Pallet: 2560Quantity:
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
-
Shipping AvailableAvailable for immediate shipment
Purchase history
NIBCO
S-685-66-LF
1/2 in. Silicon Bronze Full Port Female Solder 600# Ball Valve
NJ99216
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- Blowout-proof stem
- Stainless steel ball and stem
- Dezincification resistant
- Valve pressure rating 600 psi/41.4 bar non-shock cold working pressure
- Full port
- PTFE seats
- Solder end connections
Product Information
-
Lead Law Compliant
Dimensions & Measurements
End Connection 1
Female Sweat
End Connection 2
Female Sweat
End Connections
Female Sweat
Pressure Class
600#
Pressure - Maximum
100 psi
Valve Size
1/2 in
Characteristics & Features
Collection
S-685-66-LF
Handle Material
Plated Steel
Material
Silicon Bronze
Material Type
DZR
Proposition 65
WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
Valve Body Style
2 piece
Valve Operator
Lever Handle
Valve Port Opening
Full Port
Valve Seat Material
PTFE
Valve Stem
Blowout-Proof
Valve Type
Ball Valve
Electrical & Operational Information
Maximum Temperature
300
Warranty & Product Information
ANSI
ANSI 61, ANSI 372
FM Approved
No
IAPMO Listed
No
Lead Law Compliance Level
Lead Law Compliant and Certified
Lead Law Compliant
Yes
MSS
MSS SP-110, MSS SP-145
NSF
NSF 61, NSF 372
NSF Certified
Yes
UL Listed
No
UPC
039923319531
