1-1/2 in. Silicon Bronze Conventional Port FNPT 600# Ball Valve
NIBCO
T-580-66-LF 1-1/2 in. Silicon Bronze Conventional Port FNPT 600# Ball Valve
Package Quantity Info:
Each: 1 Inner Pack: 5 Case: 10 Pallet: 180Quantity:
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
-
Shipping AvailableAvailable for immediate shipment
Purchase history
NIBCO
T-580-66-LF
1-1/2 in. Silicon Bronze Conventional Port FNPT 600# Ball Valve
NL95HXC
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- Valve pressure rating 600 psi 41.4 bar non-shock cold working pressure
- Max temperature rating 300°F
- Conventional port
- Silicon Performance Bronze body
- Blowout-proof stem
- Threaded end connections
- Dezincification resistant
Product Information
-
Lead Law Compliant
Dimensions & Measurements
End Connection 1
FPT
End Connection 2
FPT
End Connections
FPT
Pressure Class
600#
Pressure - Maximum
100 psi
Valve Size
1-1/2 in
Characteristics & Features
Collection
T-580-66-LF
Handle Material
Plated Steel
Material
Bronze, Plastic, Steel
Proposition 65
WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
Valve Body Style
2 piece
Valve Operator
Lever Handle
Valve Port Opening
Standard Port
Valve Seat Material
Reinforced PTFE
Valve Stem
Blowout-Proof
Valve Type
Ball Valve
Electrical & Operational Information
Maximum Temperature
300
Warranty & Product Information
ASTM
ASTM A-276, ASTM B-584
FM Approved
No
IAPMO Listed
No
Lead Law Compliance Level
Lead Law Compliant and Certified
Lead Law Compliant
Yes
MSS
MSS SP-110, MSS SP-145
NSF Certified
No
UL Listed
No
UPC
039923339010
