2-1/2 in. Bronze Conventional Port NPT 250# Ball Valve

NIBCO

T-580-70-UL 2-1/2 in. Bronze Conventional Port NPT 250# Ball Valve

  • Fast #
  • Part #NT58070ULL
  • Item #4436520
  • Manufacturer Part #NL9502E
3.1 out of 5 Customer Rating
Brand image
NIBCO Bronze Conventional Port Threaded 600# Ball Valve
NIBCO Bronze Conventional Port Threaded 600# Ball Valve
NIBCO

T-580-70-UL 2-1/2 in. Bronze Conventional Port NPT 250# Ball Valve

  • Fast #
  • Part #NT58070ULL
  • Item #4436520
  • Manufacturer Part #NL9502E
3.1 out of 5 Customer Rating
X Points

EACH
Pro Pricing Displays discounted prices List Pricing Displays catalog prices No Pricing Removes prices from page

Package Quantity Info:

Each: 1 Inner Pack: 2 Case: 6 Pallet: 120
Looking for compatible parts?
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
  • Pick Up   Not Available
    0  in  Hilliard, OH
    0 nearby
  • Shipping Available
    Available for immediate shipment

Product Details

Product Details

  • Valve pressure rating 250 psi/17.2 bar non-shock LP gas per UL842
  • Conventional port
  • Chrome plated brass ball, silicon bronze stem
  • Blowout-proof stem
  • Standard lever handle, zinc plated, Plastisol coated
  • Threaded end connections
  • Dezincification resistant
  • Use in U.S. drinking water applications is prohibited after January 3, 2014
  • CSA certified to ANSI/ASME B16.33 and CGA 3.16 for natural and propane gas to 125 psig (1/4" to 1")
  • CUL YSDT7
  • Requires Certification

Specifications

ANSI:
ANSI B16.33
ASME:
ASME B16.33
ASTM:
ASTM B 16 Alloy C36000, ASTM B 371 Alloy C69430, ASTM B 99 Alloy C65100, ASTMB 124 Alloy C37700, ASTM B 584 Alloy C84400
CSA Certified:
CSA B16.33
Clean Bagged:
No
Collection:
T-580-70-UL
End Connection 1:
FIPT
End Connection 2:
FIPT
End Connections:
FIPT x FIPT
FM Approved:
No
Fire Suppression System Rated:
No
Handle Material:
Zinc Plated Steel
Height:
3-4/5 in
IAPMO Listed:
No
Length:
9-7/10 in
MSS:
MSS SP-110
Material:
Bronze
Material Type:
RPTFE
Maximum Temperature:
250
NSF Certified:
No
Origin:
Domestic
Pressure - High:
250
Pressure - Maximum:
250 psi
Pressure Class:
250#
Proposition 65:
WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
Recommended Valve Application:
Gas
Temperature Range:
-20 to 125 Deg F
UL Listed:
Yes
UPC:
039923675750
Valve Body Material:
Bronze Alloy
Valve Body Style:
2 piece
Valve Disc Material:
Brass
Valve Operator:
Lever Handle
Valve Port Opening:
Standard Port
Valve Seat Material:
RPTFE
Valve Size:
2-1/2 in
Valve Stem:
Blowout-proof
Valve Type:
Ball Valve
Weight:
8.249 lb
Width:
5-2/5 in
cUPC Certified:
Yes
