2 in. DZR Silicon Bronze Full Port NPT 600# Ball Valve
NIBCO
T-685-66-LF 2 in. DZR Silicon Bronze Full Port NPT 600# Ball Valve
Package Quantity Info:
Each: 1 Inner Pack: 2 Case: 8 Pallet: 320
How to get it:
-
-
Shipping Not AvailableNot available at this time
Purchase history
NIBCO
T-685-66-LF
2 in. DZR Silicon Bronze Full Port NPT 600# Ball Valve
NL9921D
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- Blowout-proof stem
- Stainless steel ball and stem
- Dezincification resistant
- Valve pressure rating 125 psi to 100°F
- Maximum temperature 180°F/ 82°C
- EPDM seat disc
- FIP x FIP end connections
Product Information
-
Lead Law Compliant
Dimensions & Measurements
End Connection 1
NPT
End Connection 2
NPT
End Connections
NPT
Pressure Class
600#
Valve Size
2 in
Characteristics & Features
Collection
T-685-66-LF
Material
Silicon Bronze
Material Type
DZR
Proposition 65
WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
Valve Body Style
2 piece
Valve Operator
Lever Handle
Valve Port Opening
Full Port
Valve Seat Material
PTFE
Valve Type
Ball Valve
Electrical & Operational Information
Maximum Temperature
300
Pressure - High
600
Warranty & Product Information
ANSI
ANSI 61-8, ANSI 372
ASTM
ASTM B-16, ASTM A-240, ASTM A-276, ASTM B-283, ASTM A-351
FM Approved
No
IAPMO Listed
No
Lead Law Compliance Level
Lead Law Compliant and Certified
Lead Law Compliant
Yes
MSS
MSS SP-110
NSF
NSF 372, NSF 61-8
NSF Certified
Yes
UL Listed
No
UPC
039923319500
