1/4 in. DZR Silicon Bronze Full Port NPT 600# Ball Valve
You last purchased this on
NIBCO
T-685-80-LF 1/4 in. DZR Silicon Bronze Full Port NPT 600# Ball Valve
Purchase history
NIBCO
T-685-80-LF
1/4 in. DZR Silicon Bronze Full Port NPT 600# Ball Valve
NL99014
Order #
Order Date
Job Name
My PO#
Frequently Purchased Together
Product Details
Product Details
- Silicon Performance Bronze® ball and stem
- Dezincification resistant
- Valve pressure rating 600 psi/41.4 bar non-shock cold working pressure
- Full port
- Lead-free
- Blowout-proof stem
- Threaded end connections
- PTFE seat
- White handle for easy lead-free identification
- NIBCO® double-oval lead-free body marking
-
Lead Law Compliant
Specifications
- ANSI:
- ANSI 372, ANSI 61-8
- ASTM:
- ASTM B-16 C36000, ASTM B-283 C69300, ASTM B-371 C69300
- Collection:
- T-685-80-LF
- End Connection 1:
- FPT
- End Connection 2:
- FPT
- End Connections:
- FPT
- FM Approved:
- No
- Handle Material:
- Steel
- IAPMO Listed:
- No
- Lead Law Compliance Level:
- Lead Law Compliant and Certified
- Lead Law Compliant:
- Yes
- Length:
- 1-49/50 in
- MSS:
- MSS SP-110
- Material:
- Bronze, Plastic
- Material Type:
- Virgin PTFE
- Maximum Temperature:
- 300
- NSF:
- NSF 372, NSF 61-8
- NSF Certified:
- Yes
- Pressure - High:
- 600
- Pressure Class:
- 600#
- Proposition 65:
- WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
- Recommended Valve Application:
- Potable Water
- UL Listed:
- No
- Valve Body Material:
- Bronze
- Valve Body Style:
- 2 piece
- Valve Operator:
- Lever Handle
- Valve Port Opening:
- Full Port
- Valve Seat Material:
- Virgin PTFE
- Valve Size:
- 1/4 in
- Valve Stem:
- Blowout-proof
- Valve Type:
- Ball Valve
- Weight:
- 0.52 lb
