This product requires certification to purchase.

1-1/2 in. Forged Brass Full Port Threaded 600# Ball Valve

You last purchased this on

NIBCO

T-FP-600A 1-1/2 in. Forged Brass Full Port Threaded 600# Ball Valve

  • Fast #
  • Part #NTFP600AJ
  • Item #1893324
  • Manufacturer Part #NL998HC
3.7 out of 5 Customer Rating
Brand image
NIBCO Polished Chrome Forged Brass Full Port Threaded 600# Ball Valve
You last purchased this on

NIBCO

T-FP-600A 1-1/2 in. Forged Brass Full Port Threaded 600# Ball Valve

  • Fast #
  • Part #NTFP600AJ
  • Item #1893324
  • Manufacturer Part #NL998HC
3.7 out of 5 Customer Rating
X Points
EACH
Pro Pricing Displays discounted prices List Pricing Displays catalog prices No Pricing Removes prices from page

Package Quantity Info:

Each: 1 Inner Pack: 1 Case: 2 Pallet: 420
Looking for compatible parts?
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
Add $45.00 more to cart to get FREE Shipping
  • Pick Up: Not available
  • Shipping: Available for immediate shipment

Frequently Purchased Together

Product Details

Product Details

  • Valve pressure rating 600 psi/41.4 bar non-shock cold working pressure (1/4" to 2")
  • Valve pressure rating 400 psi/27.6 bar non-shock cold working pressure (2-1/2" to 4")
  • Full port
  • Chrome-plated brass ball and stem
  • Blowout-proof stem
  • Standard lever handle
  • Threaded end connections
  • Use in U.S. drinking water applications is prohibited after January 3, 2014
  • CSA Certified to ASME B16.44
  • CR91-002 (Threaded 1/4" to 4")
  • Requires Certification

  • Not Compliant, Approved for Non-Potable Water Applications

Specifications

ASME:
ASME B16.33, ASME B16.44
CSA Certified:
CSA B16.44
Clean Bagged:
No
Collection:
T-FP-600A
Color Finish Name:
Brass
Depth:
7-7/20 in
End Connection 1:
FIPT
End Connection 2:
NPT
End Connections:
FIPT x NPT
FM Approved:
Yes
Handle Material:
Plated Steel
Handle Type:
Lever
Height:
2-21/25 in
IAPMO Listed:
No
Lead Law Compliance Level:
Not Compliant, Approved for Non-Potable Water Applications
Length:
7-7/20 in
MSS:
MSS SP-110
Material:
Forged Brass
Maximum Temperature:
400
Minimum Temperature:
-20
NSF:
NSF 61
NSF Certified:
Yes
Number of Pieces:
2 Piece
Origin:
Global
Pressure - High:
600
Pressure - Maximum:
600 psi
Pressure Class:
600#
Proposition 65:
WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
Recommended Valve Application:
Gas, Water
Temperature Range:
-20 to 400 Deg F
Temperature Rating:
400
UL Listed:
Yes
Valve Body Material:
Brass
Valve Body Style:
Ball
Valve Bonnet Type:
Threaded
Valve Disc Material:
Stainless Steel
Valve Operator:
Lever Handle
Valve Port Opening:
Full Port
Valve Seat Material:
PTFE
Valve Size:
1-1/2 in
Valve Stem:
Blowout-proof
Valve Type:
Ball Valve
Weight:
2.4 lb
Width:
4-79/100 in
cUPC Certified:
Yes
