3 in. Copper Alloy Full Port FNPT 400# Ball Valve
You last purchased this on
NIBCO
T-FP-600A-LF 3 in. Copper Alloy Full Port FNPT 400# Ball Valve
Purchase history
NIBCO
T-FP-600A-LF
3 in. Copper Alloy Full Port FNPT 400# Ball Valve
NL998XF
Order #
Order Date
Job Name
My PO#
Frequently Purchased Together
Product Details
Product Details
- Valve pressure rating 600 psi/41.4 bar non-shock cold working pressure (1/4" to 2")
- Valve pressure rating 400 psi/27.6 bar non-shock cold working pressure (2-1/2" to 4")
- Full port
- Blowout-proof stem
- Standard lever handle
- Threaded end connections
- IAPMO listed to NSF/ANSI-61-8, NSF/ANSI-372 and UPC-IGC-157
- CSA ANSI Z21.15 / CSA 9.1 (1/4" to 4")
- CSA ASME B16.44: 5 psig (maximum) (1/4" to 4")
- CSA ASME B16.33: 125 psig (maximum) (1/4" to 4")
-
Lead Law Compliant
Specifications
- ANSI:
- ANSI 372, ANSI 61, ANSI Z21.15
- ASME:
- ASME B16.33, ASME B16.44
- CSA Certified:
- CSA 9.1, CSA B16.44, CSA B16.33
- Clean Bagged:
- No
- Collection:
- T-FP-600A-LF
- Color Finish Name:
- Brass
- Depth:
- 11-17/25 in
- End Connection 1:
- Threaded
- End Connection 2:
- Threaded
- End Connections:
- Threaded
- FM Approved:
- No
- Handle Material:
- Steel
- Handle Type:
- Lever
- Height:
- 4-23/25 in
- IAPMO Listed:
- Yes
- Lead Law Compliance Level:
- Lead Law Compliant and Certified
- Lead Law Compliant:
- Yes
- Length:
- 11-17/25 in
- MSS:
- MSS SP-110, MSS SP-145
- Material:
- Forged Brass, Plastic
- Material Type:
- PTFE
- Maximum Temperature:
- 250
- Minimum Temperature:
- -20
- NSF:
- NSF 372, NSF 61
- NSF Certified:
- Yes
- Number of Pieces:
- 2 Piece
- Origin:
- Global
- Pressure - High:
- 400
- Pressure - Maximum:
- 600 psi
- Pressure Class:
- 600#
- Proposition 65:
- WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
- Recommended Valve Application:
- Potable Water
- Temperature Range:
- Up to 250 Deg F
- Temperature Rating:
- 250
- UL Listed:
- UL 125/UL 1477/UL 258/UL 842
- Valve Body Material:
- Forged Brass
- Valve Body Style:
- Ball
- Valve Bonnet Type:
- Threaded
- Valve Operator:
- Lever Handle
- Valve Port Opening:
- Full Port
- Valve Seat Material:
- PTFE
- Valve Size:
- 3 in
- Valve Stem:
- Blowout-proof
- Valve Type:
- Ball Valve
- Weight:
- 9.36 lb
- Width:
- 7-29/50 in
- cUPC Certified:
- Yes
