300000 BTU Natural Gas Unit Heater
This product has been replaced by
Reznor 100,000 BTU Natural Gas Unit Heater with Separated Combustion Option 83% Thermal Efficiency
Manufacturer Part #UDXC0001011
Manufacturer Part #UDXC0001011
Reznor
UDX Series 300000 BTU Natural Gas Unit Heater
Package Quantity Info:
Each: 1 Inner Pack: 1
Unavailable
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
-
Shipping Not AvailableNot available at this time
Purchase history
Reznor
UDX Series
300000 BTU Natural Gas Unit Heater
UDX0001040
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- HVAC equipment products sold to licensed contractors only. Products sold in select areas only, please contact your local branch for availability in your area.
- Reznor® V3 series Model UDAP gas-fired unit heaters are available in 14 sizes ranging from 30,000 to 400,000 btu/h gas input
- Sizes 30-125 are approved for residential application
- All sizes are approved for commercial/industrial installations
- Model UDAP heaters are designed for 82-83% thermal efficiency and are approved for installation in the United States and Canada by the Canadian standards association (CSA)
- Each size cabinet is easily suspended from either 2 or 4 suspension points
- Or, an optional hanger kit for all sizes allows for ceiling mounting
- The low voltage terminal strip on the outside of the cabinet makes connecting control wiring easy with no panels to remove
- All units have a factory installed gas line nipple to the exterior of the cabinet for easy gas service connection
Specifications
- AFUE:
- 83.00 %
- AMP:
- 1, 11
- ANSI:
- ANSI Z223.1
- Application:
- Commercial, Industrial
- BTU:
- 300000
- BTU Heat Rating:
- 249000 Btu/h
- Blade Span:
- 24 in.
- Coating:
- Paint Over Galvanized Steel
- Collection:
- UDX Series
- Color Finish Category:
- Whites
- Color Finish Name:
- White, Black, Red
- Configuration:
- Horizontal
- Decibel Rating (dB):
- 59 dB
- Depth:
- 48-29/32 in
- ETL Listed:
- Yes
- Flue Size:
- 5
- Fuel Type:
- Natural Gas
- Height:
- 34-1/8 in
- Horsepower:
- 1/2 hp
- Ignition System:
- Direct Spark Ignition
- Ignitor Type:
- Electric
- Indoor Outdoor:
- Indoor
- MBH:
- 300
- Material:
- Aluminized Steel, Titanium
- Max CFM:
- 3843 cfm
- Phase:
- Single Phase
- Power Source:
- Gas
- RPM:
- 1050
- Stages:
- Single
- Supply Pipe Connection Size:
- 3/4 in
- UPC:
- 663132434473
- Vent Ducted or Ductless:
- Vent
- Vent Type:
- Power Vent
- Volts:
- 115V
- Watts:
- 1086 W
- Weight:
- 277 lb
- Width:
- 41 in
