6 in. Clamp Joint Restraint for PVC Fittings and Pipe

SIGMA

PV-Lok™ Series PWPF 6 in. Clamp Joint Restraint for PVC Fittings and Pipe

  • Fast #
  • Part #SPWPFC6
  • Item #1775591
  • Manufacturer Part #PWPF-C6
5 out of 5 Customer Rating
Brand image
SIGMA Clamp Joint Restraint for PVC Fittings and Pipe
SIGMA Clamp Joint Restraint for PVC Fittings and Pipe
SIGMA

PV-Lok™ Series PWPF 6 in. Clamp Joint Restraint for PVC Fittings and Pipe

  • Fast #
  • Part #SPWPFC6
  • Item #1775591
  • Manufacturer Part #PWPF-C6
5 out of 5 Customer Rating
X Points

EACH
Pro Pricing Displays discounted prices List Pricing Displays catalog prices No Pricing Removes prices from page

Package Quantity Info:

Each: 1 Inner Pack: 1 Case: 1 Pallet: 102
Unavailable
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
Looking for compatible parts?
How to get it:
  • Pick Up   Not Available
    0  in  Hilliard, OH
    0 nearby
  • Shipping Not Available
    Not available at this time

Product Details

Product Details

  • Machined serrations for precise pipe-wall engagement
  • Joins C900 PVC pipe to a PVC injection-mold or fabricated fitting
  • Angled serrations that increase their grip due to internal line pressure increases
  • Anti-rotational side clamping bolts for ease of installation
  • Carries a water working pressure rating equal to the pipe upon which it is installed with a 2:1 factor of safety
  • Restrainer ring and beveled back-up ring packaged with restrainer rods and bolts
  • PWPF restrainer incorporates a series of machined serrations that effectively engage PVC pipe wall, to provide positive joint security and full support of the pipe
  • The directional gripping action maximizes restraint during increased line pressures such as those resulting from surges and water hammer
  • The series PWPF incorporates a PV-LOK clamping ring, restraining rods, and two piece beveled back up ring for the PVC fitting to provide the necessary joint restraint
  • Requires Certification

Documents

SPECIFICATION

Specifications

ANSI:
ANSI A21.10, ANSI A21.11, ANSI A21.53
ASTM:
ASTM A-449, ASTM A-536 Grade 65-45-12
AWWA:
AWWA C-110, AWWA C-111, AWWA C-153
Application:
PVC Pipe
Coating:
Green Alkyd Paint
Collection:
PV-Lok™ Series PWPF
End Connection 1:
Clamp
End Connection 2:
Clamp
End Connections:
Clamp
FM Approved:
Yes
Fits Pipe Size:
6 in
Material:
Ductile Iron
Material Type:
A536
Origin:
Global
Product Type:
Joint Restraint
UL Listed:
No
UPC:
829805216290
