50 ft. 10 ga 3-Conductor Solid Copper NM-B Cable in Pink
Southwire®
50 ft. 10 ga 3-Conductor Solid Copper NM-B Cable in Pink
Package Quantity Info:
Foot: 1 Roll: 50
The quantity entered must be a multiple of 50 – for example, 50, 100, 150, and so on.
Order in multiples of 50
How to get it:
-
-
Shipping AvailableAvailable for immediate shipment
Purchase history
Southwire®
50 ft. 10 ga 3-Conductor Solid Copper NM-B Cable in Pink
63948522
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- Southwire Romex® Brand SIMpull® (nonmetallic-sheathed) Cable may be used for both exposed and concealed work in dry locations with ampacity limited to that for 60°C conductors as specified in the National Electrical Code® (NEC). Individual conductor insulation is rated 90°C as required by the NEC and by the UL product standard (UL 719) for terminations in lighting fixtures.
- NM-B cable is primarily used in residential wiring as branch circuits for outlets, switches, and other loads. NM-B cable may be run in air voids of masonry block or tile walls where such walls are not wet or damp locations. Voltage rating for NM-B cable is 600 volts.
- Individual conductors within Type NM-B Cable are not listed or marked as THHN conductors (or any other NEC recognized conductor type) and are not permitted to be installed apart from the complete Type NM-B Cable.
- Conductors routed inside panelboards and boxes (without the cable jacket) for termination therein are considered part of the complete Type NM-B Cable.
- Conductor: Bare copper per ASTM B3. Sizes #14 AWG - #10 AWG are solid. Sizes #8 AWG - #2 AWG are Class B compressed stranded per ASTM B8
- Insulation: All phases and neutral(s) are insulated with Polyvinyl Chloride (PVC) with Nylon Sheath
- Color Code: 2/C: Black, White 3/C: Black, Red, White 4/C: Black, Red, Blue, White
- Ground: Solid soft drawn bare copper with kraft paper wrap
- Binder: Kraft paper
- Jacket: Polyvinyl Chloride (PVC) jacket utilizing SIMpull® Technology
Documents
Specifications
- Cable or Wire Type:
- NM-B
- Color Finish Category:
- Pinks
- Color Finish Name:
- Pink
- Gauge (metal):
- 10 ga
- Jacket Material:
- PVC
- Length:
- 50 ft
- Material:
- Copper
- Number of Conductors:
- 3
- Stranded or Solid:
- Solid
- UL Listed:
- Yes
- UPC:
- 032886189029
- Wire Gauge (AWG):
- 10 ga
