2" ANSI 300 BSA3T Bellows Sealed Stop Valve, Cast Steel, with Throttling Plug
Spirax Sarco
BSA3T Series 2" ANSI 300 BSA3T Bellows Sealed Stop Valve, Cast Steel, with Throttling Plug
Package Quantity Info:
Each: 1 Inner Pack: 1
Log in or Create Account
Log in or Create an Account to see product availability.
How to get it:
-
-
Shipping Not AvailableNot available at this time
Purchase history
Spirax Sarco
BSA3T Series
2" ANSI 300 BSA3T Bellows Sealed Stop Valve, Cast Steel, with Throttling Plug
1843152
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- The BSA3T is a low maintenance flanged in-line Bellows Sealed Isolation Valve for use on steam, condensate, gas and other fluid applications where zero emissions from the stem seal are important.
- BSA3T is fitted with a throttling valve plug that allows close control when opening the valve
- Locking screw and stroke limiter maintains correct flow rate once the flow rate is obtained.
Specifications
- ANSI:
- ANSI 300
- ASTM:
- ASTM A-216 Grade WCB
- Application:
- Commercial, Industrial
- Collection:
- BSA3T Series
- End Connection 1:
- Flanged
- End Connection 2:
- Flanged
- End Connections:
- Flanged
- Handle Material:
- Carbon Steel
- Material:
- Cast Steel
- Maximum Temperature:
- 797
- NSF Certified:
- No
- Pressure - Maximum:
- 1116 psi
- Valve Body Material:
- Cast Steel
- Valve Disc Material:
- Stainless Steel
- Valve Operator:
- Hand Wheel
- Valve Seat Material:
- Stainless Steel
- Valve Size:
- 2 in
- Valve Type:
- Straight Supply Stop Valve
