Basket 10 in. Cast Iron Flanged Wye Valve Stainer
Titan Flow Control
BS 65-CI Basket 10 in. Cast Iron Flanged Wye Valve Stainer
Package Quantity Info:
Each: 1 Inner Pack: 1
Log in or Create Account
Log in or Create an Account to see product availability.
How to get it:
-
-
Shipping Not AvailableNot available at this time
Purchase history
Titan Flow Control
BS 65-CI
Basket 10 in. Cast Iron Flanged Wye Valve Stainer
BS65I1000
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- Versatile-high quality design: This basket strainer is available with either a full rated bolted cover(BS65) or clamped cover(BS55)
- Minimal pressure loss: Pressure loss is minimized by providing a slanted straining element design, a straight-through flow path, and a large open area ratio
- Large straining capacity: With its large body and sizable straining element, this basket strainer has the ability to store large quantities of debris without affection pressure loss - thus maximizing time between servicing
- Numerous straining element options: Straining elements are available in a variety of perforations, meshes, and materials
- Self-cleaning option: Utilizing a modified straining element, drains can be fitted with a Titan FCI ball valve to allow for the automatic cleaning or flushing of the straining element while keeping the pipeline in service
- Potable water/FDA approved coatings available
Specifications
- ANSI:
- ANSI B16.1, ANSI Class 125
- ASME:
- ASME B16.1, ASME Class 125
- ASTM:
- ASTM A-126 Grade B
- Collection:
- BS 65-CI
- End Connection 1:
- Flanged
- End Connection 2:
- Flanged
- End Connections:
- Flanged
- Fitting Sizes:
- 10 in
- Length:
- 22 in
- Material:
- Cast Iron, Cast Steel, Carbon Steel, Stainless Steel
- Material Type:
- 304
- Perforation Size:
- 1/8 in
- Pressure - High:
- 200
- Pressure Class:
- 125#, 200#
- Recommended Valve Application:
- Gas, Oil, Water
- Strainer Type:
- Basket
