8" Wall Mount Mixing Faucet, SC-Cerama Cartridges, Lever Handles, Less Nozzle

T&S Brass

8" Wall Mount Mixing Faucet, SC-Cerama Cartridges, Lever Handles, Less Nozzle

Brand image
T&S Brass

8" Wall Mount Mixing Faucet, SC-Cerama Cartridges, Lever Handles, Less Nozzle

  • Part #TB0230CRLN
  • Item #3173724
  • Manufacturer Part #B-0230-CR-LN
3.4 out of 5 Customer Rating

$1.00
EACH
Color Finish Name: Chrome Plated Select Color Finish Name

Package Quantity Info:

EA: 1 IP: 1 CA: 1
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
Add $45.00 more to cart to get FREE Shipping
  • Pick Up: Not available
  • Shipping: Available for immediate shipment

Product Details

  • Swivel outlet accepts T&S swing nozzles
  • Lock washer provided for rigid application
  • 8" wall mount mixing faucet with polished chrome plated brass body
  • Material: Polished chrome plated brass body and chrome plated metal handles
  • 1/2" NPT female eccentric inlets w/ 2" flanges
  • Adjustable centers from 7 3/4" to 8 1/4"
  • Lever handle w/ color coded indexes
  • Quarter-turn Cerama cartridges w/ check valves to prevent cross flow of water
  • Lead Law Compliant

  • ADA Compliant

Recommended Accessories


Specifications

ADA Compliant:
No
ANSI:
ANSI 61
ASME:
ASME A112.18.1
Adjustable:
Yes
Application:
Commercial
BAA Compliant:
No
Built-in Stops:
No
CSA Certified:
CSA B125.1
Cartridge Type:
Ceramic Disc
Color Finish Category:
Chromes
Color Finish Name:
Chrome Plated
Depth:
2-3/8 in
Faucet Center Size:
8 in
Faucet Connection:
FNPT
Faucet Connection Size:
1/2 in
Faucet Height:
3-86/125 in
Faucet Material:
Brass
Faucet Mount:
Wall Mount
Flow Rate:
14.53 gpm
Handle Included:
Yes
Handle Length (in):
2-313/1000 in
Handle Material:
Chrome Plated Metal
Handle Type:
Lever
Height:
3-86/125 in
IAPMO Listed -:
No
ISO:
ISO 9001
Institutional Faucet Type:
Service
Lead Law Compliance Level:
Lead Free and Lead Leaching Compliant
Lead Law Compliant:
Yes
Length:
2-3/8 in
MA Approved -:
Yes
Maximum Temperature:
180
Minimum Temperature:
40
NSF:
NSF 61
NSF Certified:
Yes
Number of Handles:
Two Handle
Number of Holes:
2 Hole
Origin:
Domestic
Pressure - Maximum:
125 psi
Pressure - Minimum:
20 psi
Product Type:
Manual, Faucet
Spout Swivel:
180°
Spout Type:
High Arc
Temperature Range:
40 to 180 Deg F
UL Listed:
No
Vandal Resistant:
No
WaterSense Labeled:
No
Weight:
4.05 lb
Width:
12-5/8 in
