3 in. Carbon Steel Full Port Butt Weld Gate Valve
Velan Valve
Figure 0064C 3 in. Carbon Steel Full Port Butt Weld Gate Valve
Package Quantity Info:
Each: 1 Inner Pack: 1Quantity:
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
-
Shipping AvailableAvailable for immediate shipment
Purchase history
Velan Valve
Figure 0064C
3 in. Carbon Steel Full Port Butt Weld Gate Valve
B10-0064C-02TY
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- Low emission design guaranteed for maximum 50 ppm emissions (valves tested to bubble-tight to 12")
- Flexible wedge design assures valve tightness on both seats in varying pressure and temperature conditions
- Seal-welded seat rings are leakproof, and Stellate 6 hard faced for long service life
- Butt weld, 150 class, full port gate, vertical, bolted bonnet (Cast), WCB body, wedge/disc surface: 13Cr (410 or CA15), seat surface: stellate 6, stem: 13Cr (410)
Documents
Dimensions & Measurements
End Connection 1
Butt Weld
End Connection 2
Butt Weld
End Connections
Butt Weld
Height
18-14/25 in
Length
11-3/5 in
Pressure Class
150#
Valve Size
3 in
Characteristics & Features
Collection
Figure 0064C
Material
Carbon Steel, Stainless Steel
Material Type
Stellite 6
Valve Body Material
Carbon Steel
Valve Body Style
Vertical
Valve Bonnet Type
Bolted
Valve Disc Material
Stainless Steel
Valve Port Opening
Full Port
Valve Seat Material
Stellite 6
Valve Stem
Outside
Valve Type
Gate Valve
Electrical & Operational Information
Maximum Temperature
850
Warranty & Product Information
API
API 600
ASME
ASME B16.34, ASME B16.10, ASME B16.5, ASME B16.25
FM Approved
No
NSF Certified
No
Recommended Valve Application
Chemical, Petrochemical, Oil, Gas, Pulp and Paper
UL Listed
No
