This product requires certification to purchase.

3 in. Carbon Steel Full Port Flanged 150# Ball Valve

Velan Valve

Memoryseal® 3 in. Carbon Steel Full Port Flanged 150# Ball Valve

  • Fast #
  • Part #VF01402SSEZM
  • Item #4480967
  • Manufacturer Part #F10-01402-SSEZ
5 out of 5 Customer Rating
Brand image
Velan Valve Carbon Steel Full Port Flanged 150# Ball Valve
Velan Valve Carbon Steel Full Port Flanged 150# Ball Valve
Velan Valve

Memoryseal® 3 in. Carbon Steel Full Port Flanged 150# Ball Valve

  • Fast #
  • Part #VF01402SSEZM
  • Item #4480967
  • Manufacturer Part #F10-01402-SSEZ
5 out of 5 Customer Rating
X Points

EACH
Pro Pricing Displays discounted prices List Pricing Displays catalog prices No Pricing Removes prices from page

Package Quantity Info:

Each: 1 Inner Pack: 1 Case: 10 Pallet: 30
Unavailable
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
Looking for compatible parts?
How to get it:
  • Pick Up   Not Available
    0  in  Hilliard, OH
    0 nearby
  • Shipping Not Available
    Not available at this time

Product Details

Product Details

  • Three-piece design for facilitated in-line service
  • Stainless steel body RPTFE seats
  • Socket weld, V3P-1000, full port, three piece valve (bolted), A105/WCB body, 316 ball & stem, glass reinforced PTFE seat, standard service
  • All component parts, rivets, linkage, and handle, are enclosed in the valve to assure trouble-free operation
  • Windows interchangeable: 12 in. frontal protection and 16 in. wide angle protection
  • Keyhole window mounting
  • Meets ANSI Z87.1 standards
  • Use shields as secondary protectors with primary protectors
  • CSA Z94.3-M92
  • Warning: Wear green faceshield windows with proper goggles or protective spectacles where injurious hazard rays exist
  • Requires Certification

Documents

SPECIFICATION

Specifications

API:
API 598, API 607, API 608, API 641
ASME:
ASME B16.10, ASME B16.34, ASME B16.5, ASME Section VIII
ASTM:
ASTM A-193 Grade B7M, ASTM A-194 Grade 2HM, ASTM A-216 WCB, ASTM A-240, ASTM A-276, ASTM A-313, ASTM F-593, ASTM F-594
Clean Bagged:
No
Collection:
Memoryseal®
End Connection 1:
Flanged
End Connection 2:
Flanged
End Connections:
Flanged
FM Approved:
No
Fire Suppression System Rated:
No
IAPMO Listed:
No
ISO:
ISO 10497, ISO 15156, ISO 15848-1, ISO 15848-2, ISO 17495, ISO 5211
Length:
8 in
MA Approved:
No
Material:
Carbon Steel
Material Type:
A216-WCB
NSF Certified:
No
Pressure - High:
150
Pressure Class:
150#
Temperature Range:
-100 to 450 Deg F (-73 to 232 Deg C)
UL Listed:
Yes
Valve Body Style:
2 piece
Valve Bonnet Type:
Bolted
Valve Operator:
Locking Lever Handle
Valve Port Opening:
Full Port
Valve Seat Material:
MPTFE
Valve Size:
3 in
Valve Stem:
Blowout-proof
Valve Type:
Ball Valve
Weight:
54 lb
cUPC Certified:
No
