1/2 in. Forged Brass 24V Electric Actuator
Victaulic
Series 753-E 1/2 in. Forged Brass 24V Electric Actuator
Points
Package Quantity Info:
Each: 1 Inner Pack: 1Purchase history
Victaulic
Series 753-E
1/2 in. Forged Brass 24V Electric Actuator
S004N69006
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- A solenoid for use with Victaulic firelock preauction and deluge devices that are electrically activated
- Optional integrated coil supervision to meet the requirements of NFPA 13
- Uses a 1/2 in | 15 mm NPT connection, wired for 24 VDC
- Pressures up to 300 psi/2056 kPa/20 bar
Specifications
- ADA Compliant:
- No
- AMP:
- 0.375
- Actuator Type:
- Electric
- Brand Model Compatibility:
- Series 769
- CE Approved:
- No
- Collection:
- Series 753-E
- End Connection 1:
- NPT
- End Connection 2:
- NPT
- End Connections:
- NPT
- Height:
- 5 in
- IAPMO Listed:
- No
- Length:
- 4 in
- Material:
- Forged Brass, Stainless Steel, Synthetic Rubber
- Material Type:
- Fluoroelastomer
- NEMA:
- NEMA 4
- NSF Certified:
- No
- UL Listed:
- Yes
- UPC:
- 883481635141
- Valve Body Material:
- Forged Brass
- Valve Seat Material:
- Fluoroelastomer
- Valve Size:
- 1/2 in
- Volts:
- 24V
- Width:
- 2-3/4 in
