4-1/2 in 60 psi 1/4 in. MNPT Dry Pressure Gauge Lead Free
WIKA
XSEL® Models 212.34 4-1/2 in 60 psi 1/4 in. MNPT Dry Pressure Gauge Lead Free
Package Quantity Info:
Each: 1 Inner Pack: 5
Log in or Create Account
Log in or Create an Account to see product availability.
How to get it:
-
-
Shipping Not AvailableNot available at this time
Purchase history
WIKA
XSEL® Models 212.34
4-1/2 in 60 psi 1/4 in. MNPT Dry Pressure Gauge Lead Free
212.34
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Details
- Warranty of 5 years
- Adjustable pointer
- Brass wetted parts
- Accuracy ±0.5%
- Excellent load-cycle stability and shock resistance
- Solid front thermoplastic case
- Positive pressure ranges to 1,000 psi (60 bar)
- XSEL™ process gauge with 5 year warranty on gauge and 10 year warranty on pressure system (see terms and conditions)
- All lower mount connection gauges are factory prepared for liquid filling
-
Not Compliant, Approved for Non-Potable Water Applications
Specifications
- ASME:
- ASME B40.100 Grade 2A
- Application:
- Chemical, Environmental Technology, Mining, Offshore, Onshore, Petrochemical
- Collection:
- XSEL® Models 212.34
- Color Finish Name:
- Black, White
- Depth:
- 3-31/100 in
- Diameter:
- 4-1/2 in
- End Connection 1:
- NPT
- End Connections:
- NPT
- Fitting Size 1:
- 1/4 in
- Fitting Sizes:
- 1/4 in
- Grade:
- 2A
- Installation Type:
- Lower Mount
- Lead Law Compliance Level:
- Not Compliant, Approved for Non-Potable Water Applications
- Material:
- Aluminum, Copper Alloy, Plastic, Pocan, Rubber, Stainless Steel
- Material Type:
- Acrylic, Buna-N, Thermoplastic
- Maximum Temperature:
- 140
- NEMA:
- NEMA 3/IP54, NEMA 4X/IP65
- NSF Certified:
- No
- Pressure - High:
- 60
- Pressure - Low:
- 0
- Proposition 65:
- WARNING: This product can expose you the chemicals including Lead and Nickel, which are known to the state of California to cause Cancer, birth defects or reproductive harm. For more information go to: www.P65warnings.ca.gov
- Temperature Range:
- -40 to 140 Deg F (-40 to 60 Deg C)
- Weight:
- 2 lb
