50-80-100 Selectable CFM Continuous Run Bathroom Exhaust Fan - Ceiling & Wall Mount - Energy Star Rated
This product has been replaced by
BROAN-NUTONE LO-PROFILE DC SERIES 50-80-100 SELECTABLE CFM VENTILATION FAN 0.3 / 0.7 / 1.0 SONES ENERGY STAR CERTIFIED
Manufacturer Part #LP510R2
Manufacturer Part #LP510R2
Broan-NuTone
LoProfile™ DC Series 50-80-100 Selectable CFM Continuous Run Bathroom Exhaust Fan - Ceiling & Wall Mount - Energy Star Rated
Package Quantity Info:
Each: 1 Inner Pack: 1 Pallet: 90Quantity:
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
-
Shipping AvailableAvailable for immediate shipment
Purchase history
Broan-NuTone
LoProfile™ DC Series
50-80-100 Selectable CFM Continuous Run Bathroom Exhaust Fan - Ceiling & Wall Mount - Energy Star Rated
LP510R
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- Selectable CFM and Continuous Run: speeds of 50-80-100 for effective ventilation and built-in continuous run technology to remove moisture and reduce the risk of mold or mildew in most full baths
- TRUE CFM™: Installed exhaust fan will not lose CFM performance even with complicated ducting, unlike the competition.
- ENERGY STAR® Certified & Meets ASHRAE 62.2
- Quiet Performance: 0.4 / 0.9 / 1.2 Sones for quiet performance, enough sound to know your fan is on
- Adjustable low CFM setting allows precise adjustment to prevent over-ventilating and maximize energy efficiency
- Adjustable time delay sets how long fan will run on high speed before returning to a continuous lower speed
- ETL listed for use over bathtubs and showers when connected to GFCI protected branch circuit (ceiling installation only)
- Powerful enough for rooms up to 90 sq. ft.
- 4" oval duct connection for installation flexibility, allows for ceiling or wall mounting . Optional 4" oval to 3" round duct adapter sold separately (LPB3)
Product Information
-
Green
Dimensions & Measurements
CFM
100 ft3/min
Depth
13 in
Duct Size
4 in
Height
4 in
Length
13 in
Width
13-3/4 in
Included Components
Lights Included
No
Characteristics & Features
Collection
LoProfile™ DC Series
Color Finish Category
Whites
Color Finish Name
White
Dimmable
No
Installation Type
Ceiling Mount, Wall Mount
LED Light
No
Material
Plastic
Material Type
Polymer
Vent Duct Material
Galvanized
Vent Duct Shape
Oval
Electrical & Operational Information
AMP
0.23
RPM
920
Sones
0.4-0.9-1.2
Volts
120V
Watts
11 W
Warranty & Product Information
CEC Compliant
For Sale in CA
Energy Star Compliant
Yes
ETL Listed
Yes
UL Listed
Yes
UPC
026715270590
