Product Details

Product Description
  • HVAC equipment products sold to licensed contractors only. Products sold in select areas only, please contact your local branch for availability in your area.
  • High efficiency up to 22.3 SEER2
  • Single zone and multizone compatible
  • Anti-corrosion fin coating
  • Quiet operation
  • Follow me mode
  • Turbo mode
  • Please note: A flare is what needs to go on the end of line to keep the nut on and make it fit securely and not leak. The line does not usually come flared so the installer has to make it
Product Information
  • Requires Certification

  • Green

Dimensions & Measurements
CFM
306 ft3/min
Depth
7-7/16 in
Height
11-11/16 in
Length
31-9/16 in
Liquid Line (OD)
1/4 in
Max CFM
291 cfm
Suction Line (OD)
1/2 in
Tonnage
1 Ton
Weight
18.7 lb
Width
31-9/16 in
Characteristics & Features
A2L Compatible
No
Auto Switching Heat
Yes
Compressor Type
Inverter
EER2
13
EER2 Range
11.7 - 23.0
HSPF2 Range
7.5 - 25.0
Indoor Outdoor
Indoor
Installation Type
Wall Mount
Line Set Connection Type
Flared
MiniSplit Parts or Accessory Type
Mini Split Kit
Multi-Zone Compatible
Yes
Proposition 65
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Refrigerant
R-410A
SEER
22.8
SEER2
23.1
SEER2 Range
15.2 - 40.0
Electrical & Operational Information
AMP
0.25
BTU
12000
BTU Cooling Rating
12000 Btu/h
BTU Heat Rating
12000 Btu/h
Decibel Rating (dB)
36.5 dB
EER
13.0
Max Fuse Size
15
MBH
12
Phase
Single Phase
Volts
208/230V
Zones
1
Warranty & Product Information
Application
Residential
Energy Star Compliant
Yes
HSPF
11.0
HSPF2
11
UPC
781889870648
