12,000 BTU - Outdoor - Single-Zone Mini-Split Heat Pump 208/230V
Durastar
12,000 BTU - Outdoor - Single-Zone Mini-Split Heat Pump 208/230V
Package Quantity Info:
Each: 1 Inner Pack: 1 Pallet: 8
Log in or Create Account
Log in or Create an Account to see product availability.
How to get it:
-
-
Shipping Not AvailableNot available at this time
Purchase history
Durastar
12,000 BTU - Outdoor - Single-Zone Mini-Split Heat Pump 208/230V
DRA1U12S1B
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- Included base pan heater
- Variable speed inverter compressor
- Anti-corrosion fin coating
- Quiet operation
- Operational temperature down to -13 oF
- Refrigeration port adaptors included
Product Information
-
Green
Dimensions & Measurements
CFM
1176 ft3/min
Depth
11-15/16 in
Height
21-13/16 in
Liquid Line (OD)
1/4 in
Suction Line (OD)
1/2 in
Tonnage
1 Ton
Weight
80.5 lb
Width
31-1/2 in
Characteristics & Features
A2L Compatible
No
Auto Switching Heat
Yes
Compressor Type
Inverter
EER2
13
EER2 Range
11.7 - 23.0
HSPF2 Range
7.5 - 25.0
Indoor Outdoor
Outdoor
Proposition 65
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Refrigerant
R-410A
SEER
21.5
SEER2
23.1
SEER2 Range
15.2 - 40.0
Electrical & Operational Information
AMP
4.05
BTU
12000
BTU Cooling Rating
12000 Btu/h
BTU Heat Rating
12000 Btu/h
Decibel Rating (dB)
55 dB
EER
14.0
Max Fuse Size
15
MBH
12
Phase
Single Phase
Volts
208/230V
Watts
1035 W
Zones
1
Warranty & Product Information
Application
Residential
Energy Star Compliant
Yes
HSPF
11.5
HSPF2
11.5
UPC
781889870631
