4 in. Ductile Iron Painted IPS Back-Up Angled Face Ring Flange
FNW®
Figure 73 4 in. Ductile Iron Painted IPS Back-Up Angled Face Ring Flange
Package Quantity Info:
Each: 1 Pallet: 320Quantity:
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
-
Shipping AvailableAvailable for immediate shipment
All Sizes
Purchase history
FNW®
Figure 73
4 in. Ductile Iron Painted IPS Back-Up Angled Face Ring Flange
FNW73PP
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- 150# flange drilling
- Cast ductile iron
- Ring-side beveled inner diameter
- Back-side marking visible when installed
- Backup flange
- Tensile strength 65 KSI minimum
- Yield strength 45 KSI minimum
- Elongation 12% minimum
- 1 mil minimum Finish Thickness
Dimensions & Measurements
End Connection 1
Flanged
End Connection 2
Flanged
End Connections
Flanged
Fitting Size 1
4 in
Fitting Size 2
4 in
Fitting Sizes
4 in
Characteristics & Features
Coating
Red Primer
Collection
Figure 73
Fitting Type
Flange
Flange Type
Backup
Material
Ductile Iron
Warranty & Product Information
ASTM
ASTM A-536
ISO
ISO 1083
UPC
781889258712
