Liquid Filled Pressure Gauge 0-160#
FNW®
Figure LFG Liquid Filled Pressure Gauge 0-160#
Package Quantity Info:
Each: 1 Inner Pack: 1 Case: 75 Pallet: 4650Quantity:
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
-
Shipping AvailableAvailable for immediate shipment
Purchase history
FNW®
Figure LFG
Liquid Filled Pressure Gauge 0-160#
FNWLFG0160L
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- Dual scale (psi/kpa)
- +/- 1.5% of full scale accuracy
- Phosphor bronze C-Shaped bourdon tube
- Black anodized aluminum pointer
- Black and red markings
- Tin/copper alloy welding
- Polycarbonate lens
- Buna N socket gasket and fill plug
- Silicone gasket at lens
- IP65 enclosure rating
Product Information
-
Not Compliant, Approved for Non-Potable Water Applications
Dimensions & Measurements
Depth
1-7/25 in
Diameter
2-1/2 in
End Connection 1
MPT
End Connections
MPT
Fitting Size 1
1/4 in
Fitting Sizes
1/4 in
Characteristics & Features
Collection
Figure LFG
Color Finish Name
White
Material
Aluminum, Brass, Copper Alloy, Plastic, Rubber, Stainless Steel
Material Type
304, Buna-N, Polycarbonate
Proposition 65
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Smart Home Enabled
No
Electrical & Operational Information
Pressure - High
160
Pressure - Low
0
Temperature Range
-4 to 150 Deg F
Warranty & Product Information
Application
Compressors, Pumps
CE Approved
No
FM Approved
No
Lead Law Compliance Level
Not Compliant, Approved for Non-Potable Water Applications
NSF Certified
No
UL Listed
No
UPC
781889195307
