3 in. 150# RF FLG WCB T8 Gate Valve Carbon Steel Body, Trim 8, Bolted Bonnet F-0064C-02TY

You last purchased this on

Velan Valve

Figure 0064C 3 in. 150# RF FLG WCB T8 Gate Valve Carbon Steel Body, Trim 8, Bolted Bonnet F-0064C-02TY

This product requires certification to purchase.
Brand image
You last purchased this on

Velan Valve

Figure 0064C 3 in. 150# RF FLG WCB T8 Gate Valve Carbon Steel Body, Trim 8, Bolted Bonnet F-0064C-02TY

  • Fast #
  • Part #VF0064C02TYM
  • Item #189839
  • Manufacturer Part #F10-0064C-02TY
5 out of 5 Customer Rating
This product requires certification to purchase.

X Points
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
Add $45.00 more to cart to get FREE Shipping
  • Pick Up: Not available
  • Shipping: Available for immediate shipment

Frequently Purchased Together

Product Details

  • Low emission design guaranteed for maximum 50 PPM emissions
  • Flexible wedge design assures valve tightness on both seats in varying pressure and temperature conditions
  • Seal-welded seat rings are leak-proof, and Stellate® 6 hard-faced for long service life
  • Universal trim: 13Cr stem, wedge in CA 15 or 13Cr faced, and CoCr alloy faced seat API trim 8 suitable for applications up to 850°F (454°C)
  • Seat face CoCr alloy hard-faced, ground and lapped to a mirror finish
  • Flexible wedge with low center stem-wedge contact, in solid CA15 (13Cr) or hard-faced with 13Cr, SS 316, Monel or CoCr alloy. Wedge is ground and lapped to a mirror finish and tightly guided to prevent dragging and seat damage
  • A CoCr alloy hard-faced CF8M wedge is also available
  • Non-rotating stem with precision ACME threads and burnished finish. Double ACME for faster operation
  • Body and bonnet joint accurately machined
  • Body and bonnet castings are precision machined
  • Requires Certification

Documents


Specifications

API:
API 598, API 600, API 603
ASME:
ASME B16.10, ASME B16.34, ASME B16.5, ASME Class 150
ASTM:
ASTM A-216 Grade WCB
Collection:
Figure 0064C
End Connection 1:
Flanged
End Connection 2:
Flanged
End Connections:
Flanged
FM Approved:
No
Handle Length (in):
10 in
Handle Material:
Malleable Iron
ISO:
ISO 10434
Length:
8 in
Material:
Carbon Steel, CoCr Alloy, Malleable Iron, Stainless Steel
Material Type:
A216-WCB, CR 13
NSF Certified:
No
Pressure Class:
150#, 285#
UL Listed:
No
Valve Body Material:
Carbon Steel
Valve Body Style:
Flanged
Valve Bonnet Type:
Bolted
Valve Disc Material:
CR 13
Valve Operator:
Hand Wheel
Valve Port Opening:
Full Port
Valve Seat Material:
CoCr Alloy
Valve Size:
3 in
Valve Stem:
Outside
Valve Type:
Gate Valve
Weight:
78 lb
