3 in. 300# RF FLG WCB T8 Gate Valve Carbon Steel Body, Trim 8, Bolted Bonnet F-1064C-02TY

You last purchased this on

Velan Valve

Figure 1064C 3 in. 300# RF FLG WCB T8 Gate Valve Carbon Steel Body, Trim 8, Bolted Bonnet F-1064C-02TY

This product requires certification to purchase.
Brand image
You last purchased this on

Velan Valve

Figure 1064C 3 in. 300# RF FLG WCB T8 Gate Valve Carbon Steel Body, Trim 8, Bolted Bonnet F-1064C-02TY

  • Fast #
  • Part #VF1064C02TYM
  • Item #207347
  • Manufacturer Part #F10-1064C-02TY
5 out of 5 Customer Rating
This product requires certification to purchase.

X Points
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
Add $45.00 more to cart to get FREE Shipping
  • Pick Up: Not available
  • Shipping: Available for immediate shipment

Frequently Purchased Together

Product Details

  • Low emission design guaranteed for maximum 50 ppm emissions
  • Flexible wedge design assures valve tightness on both seats in varying pressure and temperature conditions
  • Seal-welded seat rings are leakproof, and Satellite 6 hard-faced for long service life
  • Seat faceCoCr alloy hard-faced, ground and lapped to a mirror finish
  • Flexible wedgewith low center stem-wedge contact, in solid CA15 (13Cr) or hard-faced with 13Cr, SS 316, Monel or CoCr alloy
  • Wedge is ground and lapped to a mirror finish and tightly guided to prevent dragging and seat damage
  • A CoCr alloy hard-faced CF8M wedge is also available
  • Non-rotating stemwith precision Acme threads and burnished finish
  • Double Acme for faster operation
  • Body and bonnet jointaccurately machined
  • Requires Certification

Documents


Specifications

API:
API 600
ASME:
ASME Class 300, ASME B16.34, ASME B16.10, ASME B16.5, ASME B16.25
Collection:
Figure 1064C
End Connection 1:
Flanged
End Connection 2:
Flanged
End Connections:
Flanged
FM Approved:
No
Height:
20-11/50 in
Length:
11-3/25 in
Material:
Carbon Steel, Cast Carbon Steel, Stainless Steel
Material Type:
CR 13, Stellite
NSF Certified:
No
Pressure Class:
300#
UL Listed:
No
Valve Body Material:
Cast Carbon Steel
Valve Body Style:
Vertical
Valve Bonnet Type:
Bolted
Valve Disc Material:
CR 13
Valve Operator:
Handwheel
Valve Port Opening:
Full Port
Valve Seat Material:
Stellite
Valve Size:
3 in
Valve Stem:
Outside
Valve Type:
Gate Valve
Weight:
115 lb
