2 in. Press x Male Schedule 10 316L Stainless Steel Adapter
Victaulic
Vic-Press™ 2 in. Press x Male Schedule 10 316L Stainless Steel Adapter
Package Quantity Info:
Each: 1 Inner Pack: 1
Log in or Create Account
Log in or Create an Account to see product availability.
All Sizes
Purchase history
Victaulic
Vic-Press™
2 in. Press x Male Schedule 10 316L Stainless Steel Adapter
F020576XH7
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- Fast, easy reliable way to join schedule 10S stainless steel pipe
- Recommended on services conveying water, hydrocarbons, water/hydrocarbon mixtures, air (wet/dry/with oil vapors), other gases, vegetable and mineral oils, as well as automotive fluids such as engine oil and transmission fluid
- Sizes from ½ – 2"
- Pressures up to 500 psi / 3447 kPa / 34 bar
Dimensions & Measurements
End Connection 1
Press
End Connection 2
MNPT
End Connections
Press x MNPT
Fitting Size 1
2 in
Fitting Size 2
2 in
Fitting Sizes
2 in
Length
4-43/50 in
Pressure - Maximum
500 psi
Weight
1.40 lb
Characteristics & Features
Clean Bagged
No
Coating
Stainless Steel
Collection
Vic-Press™
Fitting Type
Straight
Material
Stainless Steel
Material Type
316
Schedule Class
10
Electrical & Operational Information
Maximum Temperature
300
Minimum Temperature
-30
Warranty & Product Information
ASME
ASME B31.1, ASME B31.3, ASME B31.9
ASTM
ASTM A-312
FM Approved
Yes
NSF
NSF 61, NSF 372
NSF Certified
Yes
UL Listed
Yes
UPC
883481067294
